Functions

To switch through the different values in the display press FUNCTION.
LCD­window 1 shows the elapsed time in which the attached device has been
using electricity. At first the two right digits show seconds, then minutes. The
first two digits show hours. After 24 hours the display starts at 0 and 1 is added
to the number of days. Please note that the time recording will only start at
approximately 2 watts usage by the attached device.
Mode 1) Time/Consumption/Cost
Window 2: Shows the wattage currently used.
Window 3: The total cost of the electricity used (COST).
Mode 2) Time/Electricity Used/Days
Window 2: The total use in kilowatt hours (KWh).
Window 3: How many days the attached device has been connected and has been
using power (DAY).
Mode 3) Time/Voltage/Frequency
Window 2: The current voltage (V).
Window 3: The current frequency in hertz (Hz).
22
Mode 4) Time /Ampere/Power Factor
Window 2: The actual power consumption in ampere (A).
Window 3: The current power factor (POWER FACTOR). The factor value can range
from 0.00 to 1.00 and is equivalent to the cos φ.
Mode 5) Time/Lowest Consumption
Window 2: The lowest registered wattage during use (W).
Window 3: The display „Lo".
Mode 6) Time/Highest Consumption
Window 2: The highest registered wattage during use (W).
Window 3: The display „Hi".
Mode 7) Time/Price
Window 3: The input price per kilowatt hour (COST/KWh).
