8 Annex
Technical drawings All dimensions stated in mm; general tolerance
8.2
DIN ISO 2768 -mK
Dimensional drawing 2800
4
Connection technique
K (flying lead)
L (M23 connector;
17-pin)
L Cable length as per type code
46
Technical drawings
3.3
45
52
-0.05
-0.1
38
15
L
57
L
L
Cable lengths available:
030 / 050 / 150 / / 200 /250 / 400 /
600 / 700
Cable lengths available:
030 / 050 / 150 / / 200 /250 / 400 /
600 / 700
Lenord + Bauer
GEL 2800
