Su
(1)Base Plate-a1
(1)Base Plate-b1
(8)M6x10 Bolt
Allen Head
(4)M4 Spacer-A
(4)M8 Washer-F
(4)M8x20 Bolt-L
(1)Junction Plate-a2
(1)Junction Plate-b2
(4)M6 Nut1
(8)5mm M6/M8
Spacer-B
(4)M4x12 Bolt-G
(4)M8x35 Bolt-M
(1)TV Bracket1-a3
(1)TV Bracket1-b3
(4)M6 Nut2
(4)20mm M6/M8
Spacer-C
(4)M4x30 Bolt-H
(4)M8x45 Bolt-N
2
Supplied Parts List
(1)TV Bracket2-a4
(1)TV Bracket2-b4
(1)Allen Key
(4)M4 Washer-D
(4)M6x20 Bolt-J
(1)Wrench
(4)M6 Washer-E
(4)M6x35 Bolt-K
(2)Soft Pad
