peerless-AV ECMU-series Anbringung Und Zusammenbau Seite 5

Place adapter box (D) onto support column (B) as
2
shown.
B
Adjust swivel to desired position as shown. Secure
4
adapter box to support column with four 1" socket
screws (E) using a 3/16" allen wrench as shown.
E
3
D
5
I
5 of 32
Insert support column (B) into ceiling assembly
(A). Align holes of support column with holes of
ceiling assembly and secure using three 7/16" x 4"
bolts (F) and three 7/16" nuts (G) as shown.
F
A
B
Attach adapter plate (H) to adapter box (D) with
eight 3/4" socket screws (I) using a 5/32" allen
wrench as shown.
D
H
ISSUED: 06-22-10 SHEET #: 061-9054-7 07-08-15
G
