EX-1197HMS
3. Layout, Connections & Jumper Settings
3.3 Jumper Settings
The EX-1197HMS comes with the setting Self-Power. You also have the possibility
the EX-1197HMS to supply Bus-Power. For this you open the case with the two
screws on both sides. Then you must set the jumper JP1 from DIS (Disable) to ENA
(Enable). See the following picture.
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
ENA
JP1
DIS
13
