1. Description

The EX-1197HMS is a plug & play high-speed USB 3.1 (Gen1) metal hub for 7 USB
devices. The EX-1197HMS provides 5 USB-A Ports und 2 USB-C Port for devices and 1
USB-B uplink Port for PC. It supports all USB connections from 1.1 to 3.1. Via a exter-
nal power supply it is possible to provide a maximum of 900mA on each USB port. The
EX-1197HMS design fully utilize the Genesys chipset, which represents the latest in
SuperSpeed USB interface technology. It uses data transfer rates up to 5Gbit/s. It pro-
vides a secure and very high data transfer on each single port. The EX-1197HMS sup-
port the Self Powered and Bus Powered mode. In addition the EX-1197HMS is
equipped with an 15KV ESD surge protection. The EX-1197HMS is IP30 compliant.
The DIN-Rail Kit is included in the extent of delivery for installation in a 19" Rack. The
DIN-Rail kit will be tightened with two screwed on the back of the EX-1197HMS. The
EX-1197HMS can be easily installed on the wall with the included Wall Mounting Bra-
cket.
Features:
•
Compatible for USB 1.1, 2.0, 3.0 & 3.1
•
Up to 5Gbit/s
•
All Operating Systems are supported
•
15KV ESD Surge Protection
•
Certificate for

2. Extent of Delivery

Before you connect the EX-1197HMS to your PC, you should first check the contents of
the delivery:
•
EX-1197HMS
•
USB 3.1 (Gen1) Cable
•
DIN-Rail Kit (EX-6096)
•
Wall Mounting Bracket
•
Manual
