Icy Box IB-172 Handbuch Seite 5

http://www.icybox.de http://www.icybox.de
2bay mobile rack for 1x 3.5" + 1x 2.5" HDD
6. LED Indication
Action
Power on
HDD access
7. Assembly of HDD and into PC
1.
8. Configuration on the Back Panel
9. Function
Each HDD is only ("1 to 1") passed through to Mainboard. The two HDD remain independent from each
other and the computer sees 2 independent drives.
HDD 1
HDD 2
LED Indication
LED shines blue (only with HDD)
LED blinks purple
2.
SATA2
SATA1
Host 1
Host 2
IB-172 Series
3.
Mainboard
5 5
4.
