2bay mobile rack for 1x 3.5" + 1x 2.5" HDD
1. Model – HDD – Host Interface – Colour
Model HDD
IB-172SK-B 1x 3.5"+ 1x 2.5" SATA I/II/III
2. Package Content
1x 2bay internal HDD enclosure, 2x SATA cable, 2x key, 4x screw, 1x manual
3. Key Features
• 1x 3.5" + 1x 2.5" SATA HDD in 1x 5,25" bay
• Easy Swap® – tool less HDD or SSD installation and exchange
• Hard disk capacity not limited
• SATA III host interface 6 Gbit/s
• Key lock on HDD panel
• LED for power and HDD access
• Plug & play and hot swap
• Support all OS systems
4. Technical Data
Interface:
1 x 4pin Molex power connector
2 x 7pin SATA connector
Material: SECC/Plastic
Dimension:
147 x 42 x 183 mm
Weight: 520g
HDD height: 2,5" HDD max 9.5mm
5. Front Panel and Tray Lock
The tray lock has no power switching function. It locks only the tray mechanically
against improper operation or sliding out.
LED for HDD 1
LED for HDD 2
Host Interface
2x SATA III
Lock Open
4 4
IB-172 Series
Colour
black
