5 Parts overview and delivery content
- windmeter
C
2
3
12
Illustration 2: All parts of the windmeter
1 Wind cups
3 Bottom housing part
5 LED Status indicator (flashes
during data transmission)
7 Battery compartment
9 Battery compartment cover
11 Thick nut
1
6
4
10
14
13
5
7
9
11
3
12
17
15
16
2 Upper housing part
4 Thick fully threaded screw
6 Radiation protection slats
8 RESET button (reset all set-
tings)
10 Rod clamp on bottom hous-
ing part
12 Mounting rod
