Technical Information

Fireray One Parameters
Operating Voltage
Operating Current
Operating Current – Alignment Modes
Response Thresholds (25%, 35%, 55%, 85%)
(note – only 25% and 35% are EN54-12 approved)
Delay to Alarm
Delay to Fault
Operating Distance (Separation between Detector and
Reflector) (4 reflectors required for >50m, >164ft)
Rapid Obscuration Fault Threshold
Maximum angular alignment range of detector
Tolerance to beam misalignment (per EN54-12) – Detector
Tolerance to beam misalignment (per EN54-12) – Reflector
Optical Wavelength
Operating Temperature
Storage Temperature
Relative Humidity (non-condensing)
IP rating
Fire & Fault Relays (VFCO, Resistive) - Contact voltage
Fire & Fault Relays (VFCO, Resistive) - Contact current
Cable gauge
Housing flammability rating
Fireray One Dimensions and Weights
Reflective Detector, including smart base
Reflector
Minimum Typical Maximum
14 - 36
4.5 5.0 5.5
31 33 35
1.25 1.87 8.24
25 35 85
- 10
- 10
5 - 120
16 394
- 85
- - ±4.5
- ±0.5
- ±5
- 850
-20 - +55
-4 - +131
-40 - +85
-40 - +185
- - 93
- 55
- - 30
- - 2
22 - 14
0.5 - 1.6
- UL940 V0
Width (mm) Height (mm) Depth (mm)
134 182 151
100 100 10

Equipment Disposal

Unit
V
mA
mA
dB
%
- s
- s
m
feet
- %
Products marked with this symbol cannot be
Deg
disposed of as unsorted municipal waste in the
- Deg
European Union. For proper recycling, return
- Deg
this product to your local supplier upon the
- nm
°C purchase of equivalent new equipment, or
°F
dispose of it at designated collection points. For
°C
more information see: www.recyclethis.info.
°F
%RH
- -
V DC
A
AWG
mm
- -
Weight (kg)
0.7
0.1
Page 16
