Speaker Connection

Connect a pair of speakers to the unit via the SPEAKER output R, L jack (11) on the turntable's rear
panel.
Line Out (R, L) (to Connect to Amplifier Only)
The user can connect the unit to an external audio amplifier (cable not provided)
Connect the "L" & "R" line out jacks and the Aux In of the external audio amplifier
Turn on the turntable & the external amplifier. Sound will be produced by the external amplifier.
OPERATING THE TURNTABLE
Prior to use, please make sure to:
• Release the tonearm clamp and remove the stylus protector.
1. Press the Power On/Standby button to the ON position on the rear panel (14) and the light indicator
(8) will display "On".
2. Place a record on the turntable over the central spindle.
Place the 45 RPM adaptor over the central spindle when playing 17-cm EP records.
3. Set the SPEED SELECTOR (5) to 33 / 45 rpm depending on the record's speed.
4. Release the tonearm clamp and remove the stylus protector.
5. Lift the tonearm from the tonearm rest by using the lift lever.
6. Place the tonearm over the desired position of the record.
7. Gently lower the tonearm onto the record to start playing.
8. Adjust the volume (9)
9. Once the record is done playing, the tonearm will automatically stop. Lift the tonearm from the
record and put it back on the rest.
10. To stop manually, lift the tonearm from the record and return it to the rest.
11. Set the AUTO-STOP (ON/OFF) selector to the ON position to use the auto-stop function.
In the ON position, 33 RPM records will automatically stop when the end of the record is reached.
To play entire 45 RPM records, turn the Auto-Stop function OFF.
Note: Do not stop or turn the platter manually.
Moving or jarring the turntable without securing the tonearm clamp could result in damage to the
tonearm.
Replace the protective cap on the stylus when not in use.
Recording and Storing from Turntable
You can record your favourite songs on vinyl in MP3 format and store them on a computer.
Installing the Audacity Software
Go to the web-site http://www.audacityteam.org/download/ to install the Audacity software on your
computer.
• Click on "My Computer" on the desktop.
• Double-click "Audacity Set Up" to install the Audacity software. Follow the on-screen instructions.
Connecting the USB Cable (Included) to the Computer
1. Connect the provided USB cable to the PC port (12) on the rear panel and to your computer.
2. Follow the on-screen instructions to install the USB driver.
- EN 5 -
