Turn on your SlimPixx-system
Connect your SlimPixx-sticks to the controller and the controller to main voltage.
The SlimPixx-sticks should now run a rainbow test pattern on 50% brightness. You can change this in the controller software menu afterwards.
The Power1 and Power2 LEDs on your controller should now be lighting up.
Connect your RJ45 ArtNet connection from your controlling software or lighting desk to the ArtNet In on your SlimPixx-controller.
The LED „Link1" for ArtNet n now should be ON.
With correct adressing of SlimPixx-controller and your controlling software, the test pattern should disappear within 2 seconds.
RJ45 ArtNet In
RJ45 ArtNet Out
LED Out1
LED Out2
230VAC True1 In/ Out
Manual | Turn on
Bedienungsanleitung | Inbetriebnahme
Main Power1 indicator 24VDC
Main Power2 indicator 5VDC
ArtNet In indicator
ArtNet Out indicator
Reset Button
