LED
Smart card
reader status
Server
communication
Print status
Quick Installation Guide
Action Color
permanently off -
permanently on green
lighting up once green
(1 s)
lighting up once red
(1 s)
permanently off -
flashing green
lighting up once green
lighting up once red
permanently off -
permanently on green
flashing green
Description
An error occurred on the smart card reader.
The smart card reader is ready to operate.
A card is recognized on the smart card reader.
NOTE: In addition, you will hear a short beep.
A card is not recognized on the smart card
reader.
NOTE: In addition, you will hear a long beep.
There is no connection to the Personal Printing
server.
Data is exchanged with the Personal Printing
server.
A print job is triggered.
NOTE: In addition, a short beep is issued for a
single print job; two short beeps are issued
when there are additional print jobs available.
An error occurred during the server
communication process. Details about the error
are shown in the TPR Control Center (
NOTE: In addition, you will hear a long beep.
A printer has not been configured or recognized
or the status and the messages of the printer will
not be queried.
A printer has been configured and is recognized.
The status and the messages of the printer will
be queried.
Indicates the receipt of ThinPrint® print data.
[en]
14).
