Main supply connection

The connection to the main supply must be performed using the relevant J1-terminals (LINE, NEUTRAL,
Warning ! During the wiring arrange the earth-wire 2-3 cm. longer then the others wires .

Configuration of the receiver

The receiver configuration phase allows to optimize its functioning according to the particular requirements of
the plant. The unit must be configured exclusively during the installation phase and by an installer.
We recommend proceeding with the configuration of the parameters in a systematic way in order to avoid installation
troubles.
The parameters set during the configuration phase are the following:
• Identification number of the receiver
• Insertion of load in RS485 line
• Reception mode of the receiver (RS232 / RS485 / Current Loop)
• Communication rate setting (9600 / 1200 Baud)
• Connection of lenses
• Connection with the control unit
• Adjustment of the control voltage of the lens
• Connection of the cables of the positioning device and the lenses

To set the identification number of the receiver

- make sure that the unit is disconnected from the power supply (LD1 Led off)
- configure the SW1dip-switch according to the following table:
DIP-SWITCH
1234 5678
01 +--- ----
02 -+-- ----
03 ++-- ----
04 --+- ----
05 +-+- ----
06 -++- ----
07 +++- ----
08 ---+ ----
09 +--+ ----
10 -+-+ ----
11 ++-+ ----
12 --++ ----
13 +-++ ----
14 -+++ ----
15 ++++ ----
16 ---- +---
17 +--- +---
18 -+-- +---
19 ++-- +---
20 --+- +---
21 +-+- +---
22 -++- +---
23 +++- +---
24 ---+ +---
25 +--+ +---
26 -+-+ +---
27 ++-+ +---
28 --++ +---
29 +-++ +---
30 -+++ +---
31 ++++ +---
32 ---- -+--
33 +--- -+--
DIP-SWITCH
1234 5678
34 -+-- -+--
35 ++-- -+--
36 --+- -+--
37 +-+- -+--
38 -++- -+--
39 +++- -+--
40 ---+ -+--
41 +--+ -+--
42 -+-+ -+--
43 ++-+ -+--
44 --++ -+--
45 +-++ -+--
46 -+++ -+--
47 ++++ -+--
48 ---- ++--
49 +--- ++--
50 -+-- ++--
51 ++-- ++--
52 --+- ++--
53 +-+- ++--
54 -++- ++--
55 +++- ++--
56 ---+ ++--
57 +--+ ++--
58 -+-+ ++--
59 ++-+ ++--
60 --++ ++--
61 +-++ ++--
62 -+++ ++--
++++ ++--
63
64 ---- --+-
65 +--- --+-
66 -+-- --+-
DIP-SWITCH
1234 5678
67 ++-- --+-
68 --+- --+-
69 +-+- --+-
70 -++- --+-
71 +++- --+-
72 ---+ --+-
73 +--+ --+-
74 -+-+ --+-
75 ++-+ --+-
76 --++ --+-
77 +-++ --+-
78 -+++ --+-
79 ++++ --+-
80 ---- +-+-
81 +--- +-+-
82 -+-- +-+-
83 ++-- +-+-
84 --+- +-+-
85 +-+- +-+-
86 -++- +-+-
87 +++- +-+-
88 ---+ +-+-
89 +--+ +-+-
-+-+ +-+-
90
91 ++-+ +-+-
92 --++ +-+-
93 +-++ +-+-
94 -+++ +-+-
95 ++++ +-+-
96 ---- -++-
97 +--- -++-
98 -+-- -++-
99 ++-- -++-
