Setting of basic functions
Basic function:

Signal strength (

Required remote control buttons:
Funktion button
+
(press configuration buttons
1-5 within 10 seconds)
Configuration button
Configuration button
Configuration button
Configuration button
Configuration button
10 seconds after LED feedback (for the set
level) a rapid flashing sequence on the LED
is displayed (approx. 2 to 3 seconds) to show
operational readiness of the luminaire.
40
SENS)
press =
SENS
red control LED in the luminaire flashes
(feedback of last setting)
1
press = 20%
red control LED in the luminaire acknowledges 1x
2
press = 40%
red control LED in the luminaire acknowledges 2x
3
press = 60%
red control LED in the luminaire acknowledges 3x
4
press = 80%
red control LED in the luminaire acknowledges 4x
5
press = 100%
red control LED in the luminaire acknowledges 5x
