ENG
6.8

Lights and light scenes

The individual and flexible configuration of the touch buttons allows switching all electrical units
which are integrated into the KNX or Powernet system, especially lamps. The respective
switching statuses are shown in the display either as plain text or as symbols (e.g. an
incendescent lamp).
6.8.1

Controlling light

● For light control, select e.g. one room button
on the start page and then the lighting
button.
● Here you can switch the light on and off.
6.8.2

Calling up/modifying light scenes

Individual light atmospheres can be called up using light scenes, i.e. different lights are
automatically set to different brightness values in a given room. At the same time, e.g. the blind
or a linen is rolled down. In this way, individual lighting scenes for the most varied situations,
e.g. reading, watching TV or for presentations and demonstrations can easily be realized.
All settings within a scene can be adapted and then saved.
Up to 32 light scenes can be realized within a project, with a total of 40 KNX units being
controllable.
28
Fig. 48
