3. Layout & Connections

3.1 Layout

1x USB 2.0 5V Connector for
Upstream B-Port included external
Power Supply
Power LED
4x USB 2.0 Status LED
Downstream A-Port for each Port

3.2 Connections

5V Connector:
ATTENTION!!!
Use only with Power Supply which is included in delivery!
