3. Layout & Connections
3.2 Connections
USB 2.0 A-Port:
USB 2.0 B-Port:
4. Hardware Installation
Because there are large differences between PC's, we can give you only a general in-
stallation guide. Please refer your computer's reference manual whenever in doubt.
1. Connect the USB cable to the USB B-Port at the Hub.
2. Connect the included power supply to the 5V connector at the Hub.
3. Now connect the other end from the USB cable (A-Plug) to the A-Port at your PC.
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
USB 2.0 A-Port
Pin
Signal
1
VCC
2
DATA-
USB 2.0 B-Port
Pin
Signal
1
VCC
2
DATA-
10
Pin
Signal
3
DATA+
4
GND
Pin
Signal
3
DATA+
4
GND
EX-1171
