ANSMANN Racing ST4 Anleitung Seite 7

Mittelgetriebe, Servo / Center Gear, Steering Servo / atterrisseur central, servo de direction
7
125000943
125000960 M2.6x8 Screw
...............1
125000960 M3x10 Screw
...............4
125000972 Ball stud-Short
...............1
125000985 3x7x0.8
Washer
..................4
125000943
125000985
125000960
M3x10
125000914 125000972
125000960
M2.6x8
Select the servo horn matching the servo being used.
Futaba - 25t
- 7 -
125000943
125000913
3kg Steering Servo
Hitec - 24t Sanwa / JR / KO - 23t
