Installing and connecting the refrigerator
7.4

Installing the refrigerator

Proceed as follows to install the refrigerator:
➤ If you wish to drain the condensate through a hose:
Mount the outlet port (see chapter "Mounting the outlet port (optional)" on
page 17)
➤ Undo the transport lock (chapter "Releasing the lock" on page 24).
➤ Open the refrigerator drawer.
➤ Remove the blanking plugs (fig. 6, page 5).
➤ Push the refrigerator into the recess.
➤ Fix the refrigerator in place using suitable screws (fig. 6, page 5).
➤ Press the blanking plugs (fig. 6, page 5) into the openings.
7.5 Connecting the refrigerator to DC voltage
A
NOTICE!
• To avoid voltage drops and loss of performance, keep the
connection cable as short as possible and not be interrupted.
Therefore avoid additional switches, plugs or power strips.
• Disconnect the cooling device and other electric consumers from
the battery before you connect the battery to a quick charging
device. Overvoltage can damage the electronics of the device.
The refrigerator can be operated with a 12 V or a 24 V DC voltage supply.
For safety reasons, the refrigerator is equipped with an electronic system to prevent
the polarity being reversed. This protects the refrigerator against reversed polarity
when connecting to a battery and against short circuiting.
To protect the battery, the refrigerator switches off automatically if the voltage is
insufficient (see table below).
Cut-off voltage
Cut-in voltage
18
12 V
10.4 V
11.7 V
CRX
24 V
22.8 V
24.2 V
