PIAB P3010 CU Handbuch Seite 16

CU
P5010 CU
Loosen the screws
1 Compressed air
2 Vacuum
3 Exhaust
For more detailed information see dimensional drawing.
P6010 CU
P6010 CU
standard version
1 Compressed air
2 Vacuum
3 Exhaust
4 Separate blow-off (compressed air)
For more detailed information see dimensional drawing.
16
3/4" (option 1/2")
Ø3/8", Ø10mm
G3/4", G1/2", 3/4" NPSF, 1/2" NPSF
Ø16mm
G1/4", Ø10mm
G1", G3/4", 1" NPSF, 3/4" NPSF
G1", G3/4", 1" NPSF, 3/4" NPSF
G1/4", Ø10mm
P6010 CU
with separated blow-off
