3.4.2 Category 2 - System Settings

Parameter Parameter Factory Default Setting
No.
Category 2 Parameters – System Settings (press the
Heat/Cool selection 4:HC 0 Disabled
enable / disable
Room Temperature 8:Su 0 Programmer
Sensor Use and room
compensation unit
Maximum Flow 11:uF 55 55°C Maximum
Setpoint Flow Temp.
Minimum Flow 12:LF 15 15°C Minimum
Setpoint Flow Temp.
Mixing Value 13:Ar 150 150 seconds
Run Time
Pump Overrun 14:Pr 15 15 minutes
Run Time
Note
Remember to always press the green button to confirm that you want to store your
new Installer Set-Up setting. To exit the Installer Mode press the
10
INSTALLATION AND OPERATION MANUAL
Optional Setting
button to access this category)
1 Enabled
1 Programmer only. Transmits
demand and room setpoint
(no temperature displayed)
0 to 99 0°C to 99°C adjustment in 1°C steps
0 to 50 0°C to 50°C adjustment in 1°C steps
0 to 0 to 240 sec. adjustment
240 in 1sec steps
0 to 99 0 to 99 mins adjustment in 1min steps
or button.
INSTALLATION AND OPERATION MANUAL

4. Binding / Rebinding Procedure

The binding operation described below is required if:
• Any of the system components (Room Unit or RF Receiver) are replaced.
• The RF Receiver has incorrect or no binding data stored (e.g. when pre-
bound system pack components have been mismatched).
NOTE: During the binding procedure keep approximately 1m distance
between the Room Unit and the RF Receiver.
To bind/rebind:
1. Hold button on RF Receiver for 15 seconds. LED will flash red 0.1 sec ON, and 0.9 sec OFF
2. Hold button on RF Receiver for 5 seconds. LED will flash red for 0.5 sec ON, and 0.5 sec OFF.
3. Press the button on the Room Unit
4. Hold , and buttons for 2 seconds. Display will show
"InSt CO". The boiler and RF signal icons will be displayed.
5. Press the green button.
6. When Red LED on the RF Receiver goes off, the devices are bound.
7. If binding is unsuccessful, then the LED will stay on. In this case, move
the Room Unit and repeat the procedure from the beginning.
8. The LED on the RF Receiver will flash green every 10 seconds to indicate that the device is live.
9. Now go to Section 2. Installing the RC35RF to setup the system.
