9 Technical data

9.1 General

Die cast aluminum body
Supplied complete with horizontal and vertical
rotating support in painted galvanized steel
Wavelengths: 850nm, 940nm, white light

9.2 Mechanical

Dimensions: 133x112x135mm (5.2x4.4x5.3in)
Unit weight: 0.9kg

9.3 Electrical

Supply voltage/Current consumption:
• From 12Vdc up to 24Vdc, 1A max (high power, 4
LED) or 0.5A max (low power, 2 LED)
• 24Vac, 1A max (high power, 4 LED) or 0.5A max
(low power, 2 LED), 50/60Hz
State of the art SMD LED
Adjustable built-in photocell for automatic activation
and deactivation
Input for activation by means of external dry contact
Supplied with multipole cable: 4x0.34mm² (22AWG),
L=2m

9.4 Illuminators

GEKO IRH - BEAM PATTERN AND ACHIEVABLE DISTANCES FOR ONE
ILLUMINATOR
Horizon- Maximum distance
tal and
850nm,
vertical
low
beam
power
patterns
10˚ 100m
(328ft)
30˚ 60m (197ft) 84m (276ft) 60m (197ft) 60m
60˚ 40m (131ft) 56m (184ft) 40m (131ft) 40m
Tab. 3
The distances and the performance depend on the
camera/lens used and on the environmental light
conditions.
1 Achievable distances with camera in Day mode
(colour image)
10
850nm, 940nm, White
high high light,
power power high
power
140m 100m –
(460ft) (328ft)
(197ft)1
(131ft)1

9.5 Environment

Indoor/Outdoor
Operating temperature: From -40°C (-40°F) up to
+60°C (140°F)

9.6 Certifications

Electrical safety (CE): EN60950-1, EN60950-22
Electromagnetic compatibility (CE): EN50130-4,
EN55022 (Class A), FCC Part 15 (Class A)
Photobiological safety (CE): EN62471
IP protection degree: EN60529, IP66
IK protection degree: EN62262 (IK10)
UL certification: cULus Listed (TYPE 4X)
EAC certification
MNVCIRHS_1634_EN
