Connecting CVBS Output connector

Connect the CVBS output (BNC) connector to the monitor or video input.

Connecting Alarms

A1,A2,A3,A4 (Alarm Input 1,2,3,4)
You can use external devices to signal the dome camera to react on events. Mechanical or
electrical switches can be wired to the A1,A2,A3,A4 (Alarm Input 1,2,3,4) and G (Ground)
connectors.
See Program and Operation for configuring alarm input.
G (Ground)
NOTICE: All the connectors marked G or GND are common.
i
Connect the ground side of the alarm input and/or alarm output to the G (Ground)
connector.
AO1,AO2 (5VTTL Alarm Output 1,2)
The dome camera can activate external devices such as buzzers or lights. Connect the
device to the AO1,AO2 (Alarm Output 1,2) and G (Ground) connectors.
See Program and Operation for configuring alarm output.

Connecting the Power

Connect power of 24VAC or 24VDC for the dome camera.
When using a 24VDC adapter, connect the positive (+) pole to the '+' position and the
negative (-) pole to the '-' position.
• Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed Class 2 power
source only.

Getting Started

Once installed apply power to the dome camera. The dome camera will start a configura-
tion sequence.
