USING yOUR CLEANER

1. Extract power cord and plug it into the power supply.
red marker.
2. Adjust the telescopic tube to the desired height by moving the telescopic tube adjuster up
and raise or lower the handle to the most comfortable cleaning position. [6]
3. Carpet & floor Nozzle. Press the floor type selector on the nozzle
cleaning mode for the floor type.
hard Floor – Brushes are lowered to protect the floor.
Carpet – Brushes are raised for the deepest clean.
4. Switch the cleaner on by rotating the On/Off Variable Power Control Roller clockwise on the
rear of the cleaner main body. [8]
5. Adjust the power level by rotating the On/Off Variable Power Control Roller to the desired
level. [8]
6. Switch off at the end of use by rotating the On/Off Variable Power Control Roller anti-
clockwise to the end. [8] Unplug and gently pull the power cord out of the cleaner and the
cord will begin to automatically retract back into the cleaner. [9]
7. Parking and Storage - The flexible hose and tube can be parked for temporary storage while
in use [10] or in the Nanopack storage position when not in use: Retract the telescopic tube
to its storage length [6]. Remove the nozzle from the end of the telescopic tube [11] and
remove the hose handle from the telescopic tube [12]. Lift the hose latch at the rear of
the cleaner [13] and wrap the flexible hose around the product [14]. Park the hose handle
on the product [15]. Assemble the nozzle into the parking slot underneath the product
[16]. Assemble the telescopic tube into the remaining parking slot underneath the product
[17].

CLEANER MAINTENANCE

replacing the dust Bag

If the bag check indicator [1C] is red please check and, if necessary, replace the bag.
1. Remove the hose from the cleaner [2].
2. Press the Bag Door Release buttons and remove bag door [18].
3. Pull the bag collar to remove the dust bag [19] and carefully dispose the bag into a bin.
4. fit a new bag into the cleaner by inserting the bag collar into the bag holder [19].
important: the hose must be removed before removing or replacing the dust bag.
Remember: The bag check indicator may be red if an obstruction has occurred. In this case refer
to 'Removing A Blockage from the System' .
(*Certain Models Only)
FreespaceEvo__1-4_union.indd 2
[5] Do not pull the cord beyond the
[7] to select the ideal
2

Cleaning the Filters

To maintain optimum performance of your cleaner, please wash the pre-motor filter and exhaust
filter after each 5 bag changes.
To remove the pre-motor filter:
1. Open the bag door and remove the dust bag from the cleaner (see "Replacing The Dust
Bag").
2. Press the latch at the top of the pre-motor filter frame to unlock it from the cleaner. Tilt and
remove the filter from the cleaner [20].
To remove the exhaust filter:
1. Unlock the door by rotating the door along arrows indicated [21].
2. Remove the filter pack from the recess [22].
Gently tap and wash the filter packs using hand warm water [23]. Remove excess water from the
filters with a dry cloth and leave to dry fully before re-using. Reassemble filter packs once fully
dry and refit to the cleaner.
Remember: Do not use hot water or detergents. In the unlikely event of the filters becoming
damaged, fit a Genuine Hoover consumable. Do not try and use the product without a dust bag
or filter fitted.
Cleaning the permanent dust bag (depending on model)
To maintain optimum performance we recommend that you wash the permanent bag after
every 5 full bags. Empty the contents of the Bag into a bin, wash the Bag under handwarm
water, remove excess water with a dry cloth and leave to dry fully before replacing.
removing a Blockage From the System
If the bag check indicator is red:
1. Check if the bag is full. If so refer to 'Replacing The Dust Bag' .
2. If it is not full, then;
A Do the filters need cleaning? If so refer to 'Cleaning the filter' .
B. Check if there is any other blockage in the system - Use a rod or a pole to remove any
blockage from the telescopic tube or flexible hose.
C. Check for and clear any blockage in the Nozzle.
warning - The bag check indicator will turn red if the cleaner is used when full, if there is
a blockage or if the filters are dirty. If the cleaner is used for a significant period of time
with the bag check indicator is red, a thermal cut out will switch the cleaner off to prevent
overheating. The bag check indicator turn green once the cleaner has switched off to signal
that the thermal cut out has been activated. If this should happen, switch the cleaner off,
unplug and correct the fault. It will take about 45 minutes for the cut out to automatically
reset.
