2.4.3 Block Diagramm

Figure 3: Block Diagramm
www.schroff.biz
X156
X300
DC Switch
ATX

Power Supply

Backplane
X300
+3.3V 13 1 +3.3V
14 2
-12V +3.3V
GND 15 3 GND
INH# 16 4 +5V
GND 17 5 GND
GND 18 6 +5V
GND 19 7 GND
20 8 FAL#
+5V 21 9
+5V 22 10 +12V
+5V 23 11 +12V
GND 24 12 +3.3V
7
Gerätebeschreibung
X156
10
9
8 GND
7
6 +5V
5
4 GND
3 GND
2 +12V
1
+12V
12307804
