3. Inclination limit (Horizontal image alignment): Inclination limited to +/-90° max.
±90°
Lock / Unlock
screw
Torque wrench
Description of the ZOOM&FOCUS adjustment by joystick
1. ▲ : Zoom In
2. ▼ : Zoom Out
3. ◄ : Focus Near
4. ► : Focus Far
Joy stick for
Zoom / Focus control
Zoom
Control
