Quick Installation Guide
Network Camera, Ultra Low Light,
3840x2160, Day/Night, WDR, AI,
Learn more about eneo IN series
on our YouTube channel.
IND-58F0028MTLA
INB-58F0308MLA
12VDC, PoE, IP67
EN
DE

Werbung

loading

Inhaltszusammenfassung für Eneo INB-58F0308MLA

  • Seite 1 Quick Installation Guide IND-58F0028MTLA INB-58F0308MLA Network Camera, Ultra Low Light, 3840x2160, Day/Night, WDR, AI, 12VDC, PoE, IP67 Learn more about eneo IN series on our YouTube channel.
  • Seite 2 THIS DOCUMENT CABLES & PLUGS ��������������������������������������������������������������������������������������������������������������������3 SD & RESET �����������������������������������������������������������������������������������������������������������������������������7 ENGLISH ��������������������������������������������������������������������������������������������������������������������������������11 DEUTSCH �������������������������������������������������������������������������������������������������������������������������������25...
  • Seite 3 Cables & Plugs...
  • Seite 4 CONNECTION CABLES / ANSCHLUSSKABEL A - Standard English Deutsch No. Connector Description Anschluss Beschreibung Ethernet, RJ-45 port Ethernet, RJ-45 Anschluss RJ-45 compatible with 10/100 Mbps RJ-45 kompatibel mit 10/100 Mbps PoE Modular Jack PoE Buchse Stromversorgung, DC-Buchse, DC Jack Main Power, DC Jack, DC 12V DC-Buchse DC 12V 1 - RJ-45...
  • Seite 5 CONNECTION CABLES / ANSCHLUSSKABEL B - Extended / Erweitert English Deutsch No. Connector Description Anschluss Beschreibung Ethernet, RJ-45 port Ethernet, RJ-45 Anschluss RJ-45 compatible with 10/100 RJ-45 kompatibel mit 10/100 Mbps PoE Modular Jack Mbps PoE Modulbuchse Mic: Audio In Mic: Audio In Audio Input, 2-Pin Terminal Audio Input, 2-Pin Terminal...
  • Seite 6 1 - RJ-45 Pin 1 Green Pin 2 White / Green Pin 3 RX - Orange Pin 4 RX + White / Orange Pin 5 TX - Pin 6 TX + 2 - Audio Input // 3 - Audio Output 4 - Alarm In / Out Pin 1 Yellow / Black...
  • Seite 7 SD & Reset...
  • Seite 8 RESET BUTTON & SD CARD LOCATION RESET-TASTE & POSITION DER SD-KARTE Step 1: Remove the cover on the bottom of the camera by removing the screws. Entfernen Sie die Abdeckung auf der Unterseite der Kamera, indem Sie die Schrauben entfernen. Step 2: Behind the removed cover you will find the SD card slot and the...
  • Seite 9 RESET BUTTON & SD CARD LOCATION RESET-TASTE & POSITION DER SD-KARTE Step 1: Remove the cover on the bottom of the camera by removing the screws. Entfernen Sie die Abdeckung auf der Unterseite der Kamera, indem Sie die Schrauben entfernen. Step 2: Behind the removed cover you will find the SD card slot and the...
  • Seite 11 English...
  • Seite 12 TABLE OF CONTENT ABOUT THIS DOCUMENT ����������������������������������������������������������������������������������������������������13 SAFETY INSTRUCTIONS ������������������������������������������������������������������������������������������������������14 OPEN SOURCE SOFTWARE LICENSE INFORMATION ��������������������������������������������������������16 PRIOR TO USE / INSTALLATION�������������������������������������������������������������������������������������������17 Dimensions (in mm) & Specifications ..........................17 Parts supplied ..................................17 1 - INSTALLATION �����������������������������������������������������������������������������������������������������������������18 1.1 - Turret ....................................18 1.2 - Bullet ....................................
  • Seite 13 ABOUT THIS DOCUMENT In this document you will find a comprehensive description of a specific series of devices, which we have prepared with great care and accuracy in order to provide you with a deep insight into the general functions and features that characterize this series of devices. However, you should be aware that the detailed characterization presented in this document is based on the general product line.
  • Seite 14 SAFETY INSTRUCTIONS Read the safety instructions and the operating instructions carefully before installing the product. Depending on the product type, individual points may be omitted. Mounting & Installation • Ensure that the intended mounting location is suitable for the respective product (e.g. in terms of weight). •...
  • Seite 15 Operation • The devices may only be operated within the temperature and humidity ranges specified in the data sheet. • Sufficient ventilation must be provided to prevent overheating. This applies in particular to devices such as recorders and switches that can generate heat. •...
  • Seite 16 • the product detail pages on the eneo website (www.eneo-security.com), • the eneo download portal (https://datacloud.videor.com/s/eneodownloadportal). In case that previous link is broken, the latest link to the eneo download portal can be found on the respective eneo product page at www. eneo-security.com.
  • Seite 17 PRIOR TO USE / INSTALLATION • Make sure that the device is working properly and meets your requirements. • Make sure that the latest firmware is installed on the device. • Install the product in a suitable location. • Depending on the location, use the material supplied for installation. Dimensions (in mm) &...
  • Seite 18 1 - INSTALLATION 1.1 - Turret Step 1: Use the mounting template on the wall or ceiling and drill all the marked holes for the wall plugs. Step 2: If necessary, use a hammer to evenly insert the dowels into the holes you have just drilled.
  • Seite 19 1.2 - Bullet Step 1: Stick the mounting template to the wall or ceiling and drill all marked holes for the dowels. Step 2: If necessary, use a hammer to insert the dowels evenly into the holes that have just been drilled. Step 3: Align the bracket with the dowels and mount it with the supplied screws.
  • Seite 20 2 - CAMERA CONNECTION DIAGRAM Phone Internet Phone Router / Switch Router / Switch Router / Switch (PoE) Injector (PoE) NVR (PoE) Camera Camera Camera...
  • Seite 21 APP INSTALLATION Mobile 1. Search for and install the eneo INsight mobile app in the Apple App Store or Google Play Store, depending on which device you are using. Alternatively, you can also scan the corresponding QR code below to go directly to the store page.
  • Seite 22 3. To add devices, tap on Devices. If you tap on the + in the top right-hand corner, you can select the device type. Then follow the instructions in the app. If you have any problems, we recommend that you read the explanations in the main menu item Help.
  • Seite 23 Windows 1. Install the eneo Site Manager app. If the device is in the same network as the computer on which the app was installed, the new device will be recognised immediately. You can access the device from here. Download the eneo Site Manager App from: https://eneo-security.com/de/eneo-site-manager.html...
  • Seite 24 3. Alternatively, you can open the device in the browser of your choice via the context menu and change the password via the web interface. You can then access the remaining functions. 4. Once you have updated the password, you can log in to the device. Here you can configure the device settings according to your requirements and view the various device streams.
  • Seite 25 Deutsch...
  • Seite 26 INHALTSVERZEICHNIS ÜBER DIESES DOKUMENT ���������������������������������������������������������������������������������������������������27 SICHERHEITSHINWEISE �������������������������������������������������������������������������������������������������������28 OPEN SOURCE SOFTWARE LICENSE INFORMATION ��������������������������������������������������������30 VOR GEBRAUCH / INSTALLATION ��������������������������������������������������������������������������������������31 Abmessungen (in mm) & Spezifikationen ........................31 Lieferumfang ................................... 31 1 - INSTALLATION �����������������������������������������������������������������������������������������������������������������32 1.2 - Turret ....................................32 1.2 - Bullet ....................................33 2 - KAMERA ANSCHLUSSDIAGRAM �����������������������������������������������������������������������������������34...
  • Seite 27 ÜBER DIESES DOKUMENT In diesem Dokument finden Sie eine umfassende Beschreibung einer bestimmten Geräteserie, die mit großer Sorgfalt und Genauigkeit erstellt wurde, um Ihnen einen detaillierten Einblick in die allgemeinen Funktionen und Merkmale zu geben, die diese Geräteserie auszeichnen. Bitte beachten Sie jedoch, dass sich die detaillierte Charakterisierung in diesem Dokument auf die allgemeine Produktlinie bezieht.
  • Seite 28 SICHERHEITSHINWEISE Lesen Sie die Sicherheitshinweise und die Bedienungsanleitung vor der Installation des Produkts sorgfältig durch. Je nach Produkttyp können einzelne Punkte entfallen. Montage & Installation • Stellen Sie sicher, dass der vorgesehene Montageort für das jeweilige Produkt geeignet ist (z.B. hinsichtlich Gewicht).
  • Seite 29 Betrieb • Die Geräte dürfen nur innerhalb der im Datenblatt angegebenen Temperatur- und Feuchtebereiche betrieben werden. • Zur Vermeidung von Überhitzung ist für ausreichende Belüftung zu sorgen. Dies gilt insbesondere für Geräte wie Recorder und Switches, die Wärme erzeugen können. •...
  • Seite 30 • die Produkt-Detailseiten auf der eneo Website (www.eneo-security.com), • das eneo Download-Portal (https://datacloud.videor.com/s/eneodownloadportal). Sollte der vorherige Link nicht mehr funktionieren, finden Sie den aktuellen Link zum eneo Downloadportal auf der jeweiligen eneo Produktseite unter www.eneo-security.com. • das Download-Paket Ihrer Firmware. Die vollständigen Open Source Software-Lizenzinformationen für Ihr Produkt sind in dem entsprechenden Software-Download-Paket enthalten, das Sie in unserem Download-Portal finden.
  • Seite 31 VOR GEBRAUCH / INSTALLATION • Vergewissern Sie sich, dass das Gerät ordnungsgemäß funktioniert und Ihren Erwartungen entspricht. • Vergewissern Sie sich, dass auf dem Gerät die neueste Firmware installiert ist. • Installieren Sie das Produkt an einem geeigneten Ort. • Nutzen Sie für die Montage je nach Ort das mitgelieferte Material. Abmessungen (in mm) &...
  • Seite 32 1 - INSTALLATION 1.2 - Turret Schritt 1: Verwenden Sie die Montageschablone an der Wand oder Decke und bohren Sie alle markierten Löcher für die Dübel. Schritt 2: Verwenden Sie ggf. einen Hammer, um die Dübel gleichmäßig in die soeben gebohrten Löcher einzuschlagen.
  • Seite 33 1.2 - Bullet Schritt 1: Verwenden Sie die Montageschablone an der Wand oder Decke und bohren Sie alle markierten Löcher für die Dübel. Schritt 2: Verwenden Sie ggf. einen Hammer, um die Dübel gleichmäßig in die soeben gebohrten Löcher einzuschlagen. Schritt 3: Richten Sie die Halterung an den Dübeln aus und befestigen Sie sie mit...
  • Seite 34 2 - KAMERA ANSCHLUSSDIAGRAM Phone Internet Phone Router / Switch Router / Switch Router / Switch (PoE) Injector (PoE) NVR (PoE) Camera Camera Camera...
  • Seite 35 APP INSTALLATION Mobil 1. Suchen und installieren Sie die eneo INsight Mobile App, je nach verwendetem Gerät, im Apple App Store oder Google Play Store. Alternativ können Sie auch den entsprechenden QR-Code unten scannen, um direkt zur Store-Seite zu gelangen.
  • Seite 36 3. Um Geräte hinzuzufügen, tippen Sie auf Geräte. Wenn Sie auf das + in der oberen rechten Ecke tippen, können Sie den Gerätetyp auswählen. Folgen Sie dann den Anweisungen in der App. Sollten Sie Probleme haben, empfehlen wir Ihnen, die Erklärungen im Hauptmenüpunkt Hilfe zu lesen.
  • Seite 37 App installiert wurde, wird das neue Gerät sofort erkannt. Sie können von hier aus auf das Gerät zugreifen. Laden Sie die eneo Site Manager App herunter unter: https://eneo-security.com/de/eneo-site-manager.html 2. Klicken Sie mit der rechten Maustaste auf das Gerät in der Liste, um das Kontextmenü...
  • Seite 38 3. Alternativ können Sie das Gerät über das Kontextmenü im Browser Ihrer Wahl öffnen und das Kennwort über die Weboberfläche ändern. Sie können anschließend auf die übrigen Funktionen zugreifen. 4. Sobald Sie das Kennwort aktualisiert haben, können Sie sich beim Gerät anmelden.
  • Seite 40 Videor E. Hartig GmbH Exclusive distribution through specialised trade channels only. Videor E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark / Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
