Thunderbolt™ 3 Dual HDMI Adapter
INTRODUCTION
Thank you for purchasing the i-tec Thunderbolt™ 3 Dual HDMI Adapter that
will allow you to easily connect two monitors, TV or projector with HDMI
interface to a notebook, a tablet, a PC or a smartphone with Thunderbolt™ 3
port. It is possible to connect two monitors with 4K@60Hz resolution. This
product ideal for travelling thanks to its compact size, light weight and no
need to use the external power adapter.
PACKAGE CONTENTS
• i-tec Thunderbolt™ 3 Dual HDMI Adapter with cable (27 cm)
• Quick Start

SPECIFICATIONS

• 1x Thunderbolt™ 3 connector, transfer rate up to 40 Gbps
• Graphic interface: 2x HDMI (spec. 1.2):
- Two monitors max. resolution 4096x2160@60Hz
• Mode: Extend, Mirror and Primary display
• Supported colours 16 / 32 bit
• Power supply from Thunderbolt™ 3 bus, no need for external power
adapter; max. 15W
• Chipset: DSL6540&TPS65983
• OS: Requires Thunderbolt™ 3 port – Windows 10 32/64bit, Mac OS X,
Chrome OS (Google) with Intel Broadwell Processor and R51 and higher
• Product dimensions: 100 x 60 x 15 mm
• Product weight: 95 g
ADAPTER DESCRIPTION
1. 2x HDMI – for connecting monitors
2. Connecting cable with Thunderbolt™ 3 connector – for connecting
adapter to a notebook, a tablet, a PC or a smartphone with Thunderbolt™ 3
port
Once connected, the drivers will be installed automatically from the system.
1
4 | ENGLISH
2
NOTICE!
Before installing, make sure that the latest drivers and updated BIOS are
installed on your system.
CONNECTING A HDMI MONITOR
The adapter is equipped with 2x 4K@60Hz HDMI for connecting one or two
external monitors or a projector with HDMI interface. Advanced plasma and
LCD monitors and TVs can be used as an imaging equipment. Use only high-
quality HDMI cables for connecting the monitor to the adapter. During the
additional monitor installation, the screen of the laptop Mac, tablet or PC can
flicker, but this is normal.
Most problems with the adapter and connected devices can be solved by
disconnecting the adapter's Thunderbolt™ 3 cable from the Thunderbolt™ 3 port
on PC, Mac, smartphone or tablet and reconnecting it after approximately 10 s.

SAFETY INSTRUCTIONS

• Do not expose to extreme temperatures and air humidity.
• Use the device on flat surfaces – you will prevent it from slipping and
falling to the ground.
• Save the manual for a possible future use.
In cooperation with the service department:
• Check functionality after falling to water or to the ground.
• Check functionality when the cover is broken.
• Send the device back if it does not work in accordance with the user
manual.
2x HDMI Monitors
Resolution up to 4096x2160@60Hz
Quick Start
ENGLISH | 5
