Model HI-535
1
Model HI-535 ME
1
1 Minute timing switch.
2 Heating indicator light. Indicates that the
heat is going to the food and it goes out
when the set temperature is reached.
6
HI-535/ HI-535 ME
2
2 3 4

Control Panel

4 5
5 6
3 Cooker indicator light. It indicates that one
or more of the electric hotplates are on.
4 Function selector.
5 Temperature selector.
6 Control knobs for the hob.
1 Control Panel
with anti finger-mark
varnish
2 Oven seal
10
3 Grill element
11
4 Chrome Support
12
5 Grid
6 Tray with Easy-cleaning
Enamel
7 Hinge
8 Door
9 Smoke outlet
10 Fixing to unit
11 Grill screen
13
12 Light
13 Tempered inner
glass
