O O peration
1. Status display LED
The actual charging status of the Powerbank will be showed to you by the
LED status when you charge and/or discharge the Powerbank.
LED light
% - Energy
1 % - 25 %
26 % - 50 %
51 % - 75 %
76 % - 100%
2. Starting-Up / Powerbank Charge / Charging
Connected Devices
a) Charging the Powerbank
Please connect the included Micro USB cable to the micro USB port (IN) of
the Powerbank, and connect the other end of the USB cable to a standard
USB port of a computer or USB power adapter. The charging process and
current charging status is indicated by the LED status lights. If the
Powerbank is fully charged, the LED status lights remain illuminated. The
required charging time of the Powerbank depends on the selected charging
source and the output power (5V / 2.1A).
b) Charging devices through the Powerbank
This Powerbank has a USB A connection (USB OUT) (Output 5V 3.1A
max.) and a Qualcomm Quick Charge 3.0 USB A connection (USB QC OUT)
(normal output 5V 3.1A max.; Output Quick Charge 5-6V 3.1A max., 9V
2.0A max., 12V 1.5A max.).
Normal charge: Connect the supplied USB cable with the USB A
connection (USB OUT) on the powerbank and the other end of the USB
cable with the micro USB connection of the device to be charged (5V 3.1A
max. output).
Charge with Qualcomm Quick Charge 3.0: To use the Quick Charge
Technology (for further information
www.qualcomm.com/products/snapdragon/quick-charge) you need a
device supporting this standard (in case ask the producer of your device).
LED 1 LED 2
● ○
● ●
● ●
● ●
Page 5 of 8
LED 3
○
○
●
●
EN
LED 4
○
○
○
●
