Setting the Channel 1 (microphone) controls

Channel 1 is only intended for use with a dynamic handheld microphone. Do not
connect any other sources to this input.
1. Before using the microphone, adjust the Channel 1 Volume control fully counter-
clockwise.
2. While speaking into the microphone, adjust the Volume control to the desired
level.
For best results, keep the microphone close to your lips when speaking.
Holding the microphone more than 3 inches (7.6 cm) away from your lips when
speaking will lead to less overall volume and may impact overall clarity.
The Channel 1 Microphone Input is equipped with an integrated ToneMatch
preset to automatically optimize the sound of your microphone.
3. Adjust the Treble and Bass controls to make further refinements based on your
personal preference.

Setting the Channel 2 controls

When connecting an audio source to any of the Channel 2 inputs, follow these
steps to adjust the volume.
1. On the power stand, adjust the Channel 2 Volume control fully
counterclockwise.
2. Connect the audio source to the appropriate Channel 2 input.
3. Turn the Channel 2 Volume control clockwise until the volume indicator glows
green or yellow.
If the volume indicator steadily glows red, decrease the volume.
Note: You can connect multiple audio sources, one to each of the Channel 2 Inputs,
at the same time. However, you must then adjust the volume on each source device to
achieve the mix you desire.
