Operation

mounting plate of the wall thermostat is seamlessly ali-
gned to the already fixed mounting plate/retaining ring.
The wall thermostat is designed to fit into frames supplied
by the following manufacturers:
Manu- Frame
facturer
Berker S.1, B.1, B.3, B.7 glass
ELSO Joy
GIRA System 55, Standard 55, E2, E22, Event, Esprit
1-M, Atelier-M, M-Smart, M-Arc, M-Star,
merten
M-Plan
JUNG A 500, AS 500, A plus, A creation
6 Operation
After teaching-in and mounting have been performed,
simple operations are available directly on the device.
If the wall thermostat is in standby mode, please
press the control wheel (E) once before operation
to activate the device.
40
• Temperature: Turn the control wheel (E) to the
right or to the left to manually change the temper-
ature of the Homematic IP Radiator Thermostat.
In automatic mode, the manually set temperature
will remain the same until the next point at which
the profile changes. Afterwards, the defined heat-
ing profile will be activated again. During manual
operation, the temperature remains activated until
the next manual change.
• Manual and automatic mode: Press and hold
down the control wheel (E) to switch between
manual and automatic mode. In automatic mode,
the defined heating profile of the Homematic IP
app is active. In manual operation the temperature
can be set directly on the device or via the app and
will remain active until the next manual change.
• Boost function: Press the control wheel (E) short-
ly to activate the boost function for heating up the
radiator quickly and briefly by opening the valve.
There will be a pleasant room temperature right
away because of the radiated heat.
The operating lock of the wall thermostat can be
activated and deactivated via the Homematic IP
app. Tap on the menu symbol in the top left of the
screen of your app and select the menu item "De-
vice overview". Select your wall thermostat to
switch the operating lock "ON" or "OFF".
