Screw Mounting; Installation In Multiple Combinations - HomeMatic HMIP-WTH Montageanleitung Und Bedienungsanleitung

Start-up
• Fix the adhesive strips (N) on the back side of the
mounting plate (F) in the provided area. Make
sure that you can read the letters on the back
side (O) (see figure 3) and that the clips on the
mounting plate latch into the openings on the
wall thermostat.
• Remove the protective film from the adhesive
strips.
• Press the assembled wall thermostat with the
back side to the wall in the position where it
should subsequently be attached.
5.2.2

Screw mounting

For mounting the wall thermostat with screws, please
proceed as follows:
• Choose a site for installation.
Make sure that no electricity or similar lines run in
the wall at this location!
• Position the mounting plate (F) on the desired
site on the wall. Make sure that the arrow on the
mounting plate is pointing upwards.
• Use a pen to mark the positions of bore holes (P)
(diagonally opposite) in the mounting plate on
the wall (see figure 4).
38
The bore holes (Q) can be used for installation
with a flush-mounting box.
• Now drill the bore holes.
If you are working with a stone wall, drill the
marked 5 mm holes and insert the plugs supplied.
If you are working with a wooden wall, you can
pre-drill 1.5 mm holes to make screws easier to
insert.
• Use the supplied screws and plugs (R) to fasten
the mounting plate to the wall (see figure 5).
• Attach the clip-on frame (A) to the mounting
plate.
• Place the electronic unit (B) back into the frame
(see figure 1). Make sure that "TOP" and the ar-
rows on the back side point upwards and that the
clips on the mounting plate latch into the open-
ings on the electronic unit.
5.2.3

Installation in multiple combinations

You can mount the wall thermostat with the attachment
frame (A) provided or use it with frames of other manu-
facturers as well as integrate the electronic unit (B) into
a multi-gang frame. You can flexibly fix the mounting
plate (F) to the wall using adhesive strips or screws. For
mounting with multiple combinations, make sure that the
Start-up
39
