Start-up
To teach-in the wall thermostat, please proceed as fol-
lows:
• Open the Homematic IP app on your smart-
phone.
• Select the menu item "Teach-in device".
• To remove the electronic unit (B) from the frame,
take hold of the sides of the electronic unit and
pull it out (see figure 6).
• Turn over the electronic unit (B).
• Insert two new 1.5 V LR03/micro/batteries into
the battery compartment, making sure that you
insert them the right way round (see figure 7).
• Teach-in mode remains activated for 3 minutes.
You can manually start the teach-in mode for an-
other 3 minutes by pressing the system button
(D) shortly (see figure 8).
• Your device will automatically appear in the
Homematic IP app.
• To confirm, please enter the last four digits of the
device number (SGTIN) in your app or scan the
QR code (please see the sticker supplied or at-
tached to the device).
• Please wait until teach-in is completed.
• If teaching-in was successful, the LED lights up
green. The device is now ready for use.
• If the LED lights up red, please try again.
36
• Select the desired solution for your device.
• In the app, give the device a name and allocate
it to a room.
5.2

Mounting

Please read this entire section before starting to
mount the device.
You can use the supplied clip-on frame (A) to mount
the wall thermostat or easily integrate it into an exist-
ing switch (see „5.2.1 Adhesive strip mounting" on page
37).
If you want to mount the wall thermostat with the sup-
plied clip-on frame, you can use
• the supplied double-sided adhesive strips or
• the supplied screws
to fix it to a wall.
5.2.1

Adhesive strip mounting

For mounting the assembled wall thermostat with adhe-
sive strips, please proceed as follows:
• Choose a site for installation.
Make sure that the mounting surface is smooth,
solid, non-disturbed, free of dust, grease and sol-
vents and not too cold to ensure long-time ad-
herence.
