SAFETY INSTRUCTIONS
General safety instructions
Assembly, installation, commissioning and repair of
electronic devices must be carried out by qualified
electricians. Observe the latest regulations and standards
for system installations.
WARNING! Danger due to electric shock.
Observe the safety regulations according to DIN VDE
0100, when working on main power connections of 230 V.
When installing TCS:BUS systems the general safety
regulations for telecommunication systems according
to VDE 0800 must be observed. Inter alia:
> separated cable routing of high and low voltage lines,
> minimum distance of 10 cm in case of a common cable
routing,
> use of separators between high and low voltage lines within
shared cable ducts,
> use of standard telecommunication lines, e.g. J-Y (St) Y with
PRODUCT INFORMATION (BRIEF) 0.8 mm diameter,
Series TASTA > already existing lines (modernisation) with deviating
Indoor station for hands-free talking cross-sections can be used in compliance with the loop
ISW5010-0145 resistance.
Requirements to protect against lightning
German / English
ATTENTION! Device damage due to overvoltage.
By suitable lightning protection measures it has to be
ensured that the electric voltage of 32 V DC at each connec-
tion is not to be exceeded.
PRODUCT DESCRIPTION
Scope of delivery
Intended use
1 x indoor station ISW5010-0145
1 x mounting plate with connection terminal The ISW5010-0145 is an indoor station for hands-free talking.
1 x product information (brief) It can be operated in TCS audio systems and combined audio/
1 x instruction manual video systems. The indoor station is suitable for surface-mount.
PI_ISW5010-0145 Instruction manual
Device overview
11 Smart Slot
10 call OFF button
9 red LED
8 volume button
7 speech button
6 green LED
5 ambient illumination
INDICATION AND OPERATING ELEMENTS
1 > send control function 8, send internal call, door release
automatic on / off or call diversion on / off configurable
> ring tone selection: internal call
2 > switching light
> ring tone selection: floor call
> ambient illumination: press for 4 s to de-/activate the
ambient illumination
3 > open the door
> trigger light switch function, if the light switch function
is activated in the front door station
> end speaking: the voice connection is terminated after
4 s automatically
> ring tone selection: door call 1 from the front door station
4 > OFF: door opener in standby
> ON: door release automatic is activated
> ON 3 s, door will be opened
> ambient illumination is switched on, ready for operation
> blinks: call indication, if configured
5 > OFF: temporary (manually) or permanently switched off
> ON: temporary (manually) or permanently switched on
> blinks: call indication, if configured
6 > OFF: ready for operation
> ON: call, speaking is activated
> blinks 3 x: busy speech channel
7 > shortly press: call acceptance, speaking is activated
> press for 2 s: activate duplex communication
> end speaking
> ring tone selection: door call 2 from front door station
8 > Setting the ring tone volume, if no voice connection is
established.
> Setting the volume voice output when a voice connection
is established.
9 > OFF: call OFF is deactivated
> ON: call OFF is activated
> blinks: ring tone programming mode
> flashes: call diversion is activated, call OFF is deactivated
10 > shortly press: ring tone mute is activated
> press for 8 s: initiate/end mode ring tone selection
11 > for additional signaling of a door call, available as
accessory
TECHNICAL DATA
supply voltage .................. +24 V ± 8 %
(power supply and control unit)
2-wire operation .............. input current: I(a) = 1.96 mA
I(max) = 21.30 mA
3-wire operation .............. input current: I(a) = 0.16 mA
I(P) standby: 1.71 mA
I(Pmax): 6.88 mA
I(max) = 20.7 mA
degree of protection ........ IP30
acceptable ambient
temperature ..................... 5 ...+ 40 °C
housing ............................ plastics ASA
dimensions (in mm) ............ H 105 x W 94 x D 17 (mounting
plate),
T 21 (mounting tray)
weight ............................... 103 g (incl. mounting plate)
1 function button
MOUNTING AND INSTALLATION
Install the mounting plate
2 light switch button Set a flush-mount socket to stow the cables. Conect the wires
to the terminals (a, b, E, P and P). Screw the mounting plate
to the flush-mount socket.
flush-mount socket
3 door release button
4 blue LED
mounting plate
Install the mounting tray Error detection and indication
If the installation of a flush-mounted socket is not Indication error mode, if error detected: All 3 LEDs are flashing.
possible, use the mounting tray. The mounting tray is Pressing any button of the device triggers the output of an
available as an accessory (article: E37417). error tone.
Remove the device Error tone - error causes and troubleshooting
Insert a screw driver with slight pressure into the release
opening (1). Pull off the device to the front at its upper side. The error tone sounds 1 x long and 3 x short:
Lift the device out of the adjustment increments (2). > a- and P-wire are exchanged or short-circuited
> exchange a- and P-wire or remove short-circuit, device is
Snap on the device in standby mode again
Put the device onto both adjustment increments of the mount-
ing plate (1). Press the device against the latch until it snaps The error tone sounds 1 x long and 2 x short:
on (2). > a-wire: not connected or not supplied
> connect a-wire or check power supply, device is in standby
mode again
2
The error tone sounds 1 x long and 1 x short:
> button stucks (pressed longer than 15 s)
> loosen the button at the device or the floor push button,
1 device is in standby mode again
2-wire/ 3-wire operation
> 2-wire operation (delivery state): The jumper J1 is set for
1
2-wire operation.
> 3-wire operation: Plug the jumper J1 onto both upper contacts
or remove the jumper J1.
1
2 2-wire operation
Remove the device Snap on the device
3-wire operation
Example circuit: 3-wire operation
PROGRAMMING A BELL BUTTON
floor push-button
ISW5010 Basic principle
All TCS:BUS devices are equipped with an unique serial number.
The serial number of an indoor station is allocated to a bell
button of a front door station. The allocation is stored in the
PUK01 EEPROM of the front door station.
Preconditions for the programming:
> Ensure that the access to the indoor station in the flat is
granted.
BVS20 > Check if the indoor station is connected to the TCS:BUS.
> Switch on the mains power. The operating LED at the
control unit is on.
> Check if the programming lock is activated. If it is activated,
you cannot program any bell button. See manual Service
Example circuit: 2-wire operation Device TCSK and configo
> For device-specific indication modes of the front door station
see product information of the front door station.
floor push-button
ISW5010
PUK01
RUN/PROG button
BVS20
LED
Connect the floor push-button
Connect the floor push button to the terminals E – P an.
Alternatively you -door station.
1. Control unit:
Switch on the programming mode of the system
COMMISSIONING > shortly press the RUN/PROG button
> LED blinks
Install all devices of the system completely. Check the a-, > programming mode is acktivated
b- and P-wire against each other on short-circuit. Switch on
2. Programming via voice connection
the mains power.
If the floor push button does not work, check if it is > press the speech button
connected to the a-wire of the power supply unit. > shortly press the bell button
> a ring tone sounds at the front door and indoor station
> press the speech or door release button
3. Control unit:
Switch off the programming mode of the systems
> shortly press the RUN/PROG button
> LED lights up
> the programming mode is switched off
Delete a bell button
b)
> press the button for around 6 s until an acknowledgement
tone sounds
c)
> release the bell button
> before execute step 1 and then step 3
Notes:
Do NOT press the RUN/PROG button longer than 5 s.
a)
Otherwise you'll activate the light switch function at the
front door station. The bell button cannot be programmed.
Remedy:
> If the LED blinks, shortly press the RUN/PROG button to
switch off the programming mode.
> Press the RUN/PROG button shortly to switch in the
programming mode.
> Then program the bell button.
Not necessary, if the bell buttons have not been pro-
b)
grammed, comp. product information of the front door
station.
If there sounds a Progsperr tone (long high-frequency tone,
c)
long low-frequency tone) instead, the front door station is
equipped with a programming lock.
The programming lock can be deactivated only with the
d)
Service Device TCSK or the configuration software configo™.
Further information (parallel call with only one bell
button) can be found in the system manual, in the down-
load area at www.tcsag.de or by scanning the QR code.
NOTES
Conformity
Declarations of conformity are available for
download www.tcsag.de.
Information on disposal
Dispose the device separately from domestic waste
via a collection point for electronic scrap. Ask your
county administration for the responsible collection
point.
Dispose the parts of the packaging in collecting
tanks for cardboard and paper resp. plastics.
SERVICE
For detailed information visit our website www.tcsag.de.
Downloads or scan the QR code.
HOTLINE
TM
Fon +49 4194 9881-188, Fax +49 4194 9881-189
E-Mail hotline@tcsag.de
ORDER DIVISION
speech button Fon +49 4194 9881-166
ISW5010 Fax +49 4194 9881-169
E-Mail offer@tcsag.de
bell button SALES
PUK01 Fon +49 4194 9881-144
Fax +49 4194 9881-149
E-Mail sales@tcsag.de
TRAINING COURSES
BVS20 Fon +49 4194 9881-155
Fax +49 4194 9881-159
E-Mail schulungen@tcsag.de
TCS TürControlSysteme AG
Geschwister-Scholl-Straße 7
D-39307 Genthin
Fon: +49 3933 8799-10
a)
Fax: +49 3933 8799-10
TCS Österreich GmbH
Gewerbepark 21
A-2821 Lanzenkirchen
c) 09/2016, Subject to technical changes,
kPI_ISW5010-0145, Version 1A,
www.tcsag.de
