S•Com Plus Features - Samson S-Com Plus Bedienungsanleitung

GAIN REDUCTION dB
30 27 24 21 18 15 12 9 6 4 2 1
EXPANDER/GATE
TRIGGER THRESHOLD RATIO
-10 10
20 4:1
STEREO
COMPRESSOR GATE
LIMITER 50 0 -30 +10 2 6 15
OFF +10 1
-40 +20
dB dB dB
RELEASE ENHANCER KEY
The Samson S com Plus dynamics processor utilizes the latest technology in gain management design. Here are
some of its main features:
• Full featured, dual channel dynamics processor including Compressor/Limiter, Expander/Gate, De-Esser
and Peak Limiter.
• SKD (Smart Knee Detector) switches from soft to hard knee based on the level of input signal.
• AEG (Automatic Envelope Generator) mode constantly adjusts the Compressor's Attack and Release
times based on input signal. Manual adjustment of Attack and Release time is also facilitated.
• 12 Segment LED Input/Output Meter, plus 12 Segment LED Gain Reduction Meter.
• External Keying with Key Switch available on front panel.
• Adjustable De-Esser with independent LED meter for reducing annoying sibilance from recorded tracks.
• Expander/Gate with variable Trigger control and switchable Fast and Slow Release time.
• Gate function can be switched from hard Off to Light Downward Expander.
• Gate Open and Closed LED's.
• Peak Limiter with independent Threshold control and Peak LED.
• Advanced circuit design, utilizing low noise operational amplifiers and high quality VCAs.
• Stereo Link Switch.
• Servo balanced inputs and outputs on XLR and 1/4" connectors.
• Switchable +4 and –10 operating levels.
• High quality 41 position detent pots and backlit switches.
• The stylish bead blasted electric blue anodized front-panel is as easy to read as it is to look at.
• Three-year extended warranty.
INPUT / OUTPUT LEVEL dB DE-ESSER LEVEL dB LIMIT
-30 -24 -18 -12 -6 -3 0 +3 +6 +9 +12 +18 0 -3 -6 -9 -12
CH 1 STEREO LINK
COMPRESSOR / LIMITER DE-ESSER
ATTACK RELEASE OUTPUT LEVEL LIMITER
0
50 1 5 +12
200 .15 3 -10 +10 3 7 +5 16
.3 300 .05 5 0 10 0 OFF
-20 +20
mSec dB
Sec dB dB
AUTO I/O METER IN/OUT
Auto Envelope S m a r t K n e e
GENERATOR D E T E C T O R
S•com plus Features
GAIN REDUCTION dB INPUT / OUTPUT LEVEL dB
30 27 24 21 18 15 12 9 6 4 2 1 -30 -24 -18 -12
EXPANDER/GATE COMPRESSOR / LIMITER
TRIGGER THRESHOLD RATIO ATTACK
-10 10
20 4:1 50
IN/OUT 1 GATE
50 0 -30 +10 2 6 15 200
IN/OUT 2
OFF +10 1 .3 300
-40 +20
dB dB dB mSec
RELEASE ENHANCER KEY AUTO
E n h a n c e d
F r e q u e n c y
R E C O V E R Y
5
DE-ESSER LEVEL dB LIMIT
-6 -3 0 +3 +6 +9 +12 +18 0 -3 -6 -9 -12
POWER
CH 2
DE-ESSER
RELEASE OUTPUT LEVEL LIMITER
0
1 5 +12
.15 3 -10 +10 3 7 +5 16
.05 5 0 10 0 OFF
-20 +20
dB
Sec dB dB
I/O METER IN/OUT
