3. Layout, Connections & Jumper Settings

3.1 Layout

Front:
Back:
Power LED
5V T-Block for optional
external Power Supply or to
connect the EX-K1110

3.2 Connections

+5V T-Block:
GND (Ground)
+5V
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
4x USB 3.1 (Gen1)
Downstream A-Port
ATTENTION!!!
Never connect power to GND, it will destroy
your Hardware!!!
10
EX-1180HMS
1x USB 3.1 (Gen1)
Upstream B-Port
