Start-Up
Response to errored
SIMOLINK telegrams
Setpoint adjustment
to the machine
velocity
6-4
02.2001
The SIMOLINK Pulse Generator updates the setpoint output in
response to every SYNC interrupt with which error-free data are
received. If a communications error occurs, the generator continues to
operate on the old setpoint. If CRC errors occur 8 times in succession,
it sets the frequency generator directly to 0 Hz and does not restart it
until an error-free setpoint is received. It switches to 0 Hz immediately if
communication on the SIMOLINK is aborted.
The frequency output of the SIMOLINK pulse generator in the 90°
pulses mode is identical to that of a pulse generator with 1000
pulses/rev and a speed normalization of 100 % = 1500 rev/min. If the
generator is to simulate shaft encoders with other pulse numbers per
revolution or different speed normalization, the setpoint to the SLP must
be renormalized. This can be done, for example, by multiplying the
machine setpoint. In this regard, it is important to note that the
maximum setpoint for the SLP on the SIMOLINK data interface must
not exceed 112 % (max. output frequency of approximately 28 kHz in
90° pulse mode).
Reference
=
Multiplier
60
Output frequency depending on operating mode:
♦ 25000
In 90° pulse mode
♦ 100000
In 100 kHz signal mode
Reference speed
[rev/min]
500
1000
1000
1500
1500
1500
1) The speed range of the SLP cannot be output with this combination
Table 6-4 Examples for 90° pulses mode
×
speed Encoder pulses/rev
×
Output frequency
No. of encoder
pulses per rev.
1000
1000
2000
1000
1024
2048
GWE-477 764 4070.76 J
Operating Instructions
SIMOLINK Pulse Generator
x 100 %
Multiplier
[%]
33.333
66.667
1)
133.333
100.000
102.400
Not displayable
