Led Indicators - Dynamite DYNC2025 Bedienungsanleitung

Li-Po Charging
OPERATION
Constant Current
Constant Voltage*
Charging Complete Alert
Charging Complete
*When the Li-Po battery reaches Constant Voltage charging, it is charged to approximately 90%. If 90% capacity is acceptable, press and hold the
Start/Stop Button for 3 seconds to end the charge cycle, then disconnect the battery.
Ni-MH Charging
OPERATION
Constant Current
Charging Complete Alert
Charging Complete

LED INDICATorS

LED COLOR
Red LED Blinking every 2 seconds
Red LED
Yellow LED Blinking every 2 seconds
Red LED
Yellow LED
Green LED Blinking once per second 5 times
All LEDs
LED COLOR
Red LED Blinking every 2 seconds
Red LED
Yellow LED
Green LED Blinking once per second 5 times
All LEDs
LED STATuS
Solid ON
Solid ON
Solid ON
Solid ON
LED STATuS
Solid ON
Solid ON
Solid ON
7
SOuND
–
–
–
–
–
1 beep per second 5 times
–
SOuND
–
–
–
1 beep per second 5 times
–
