FUNKDIMMER FÜR MONOCHROME LEDS
KONSTANTSPANNUNG 12-24VDC
One zone dim remote
43LED/535
Feature
43LED/535
This is a RF Wireless Push Remote,can be wall mounted, or sticked on wall easily by 3M glue.
Parameter
Remote
Operation
Part No.
Operation Voltage
Remarks
1 Kanal Wandanbaudimmer
Frequency
43LED/535
3VDC Cr2430 battery 434MHz/868MHz
RF Wireless
Receiver
Part No.
Iuput Voltage
Current
Output
Remarks
Batteriebetrieb
43LED/531
12-36VDC
4x700mA
4x(8.4-25.2)W
Constant current
1x8A
1x(96-288)W
43LED/530
12-36VDC
Constant voltage
Product Size
Kunststoffgehäuse mit
Glasrahmen weiß
verwendbar mit 43LED/530
86 x 86/AL 13mm
86.0
Lieferung inklusive Batterie CR2430
BestellNr.
43LED/535
Two zones dim remote
43LED/536
Feature
43LED/536
This is a RF Wireless Push Remote,can be wall mounted, or sticked on wall easily by 3M glue.
Parameter
Remote
2 Kanal Wandanbaudimmer
Operation
Part No.
Operation Voltage
Remarks
Frequency
43LED/536
3VDC Cr2430 battery 434MHz/868MHz
RF Wireless
Receiver
Batteriebetrieb
Part No.
Iuput Voltage
Current
Output
Remarks
43LED/531
12-36VDC
4x700mA
4x(8.4-25.2)W
Constant current
43LED/530
12-36VDC
1x8A
1x(96-288)W
Constant voltage
Kunststoffgehäuse mit
Product Size
Glasrahmen weiß
verwendbar mit 43LED/530
86 x 86/AL 13mm
86.0
Lieferung inklusive Batterie CR2430
BestellNr.
43LED/536
RF DIM Wall Panel Dimmer
43LED/537-W & 43LED/537-S
Feature
43LED/537
43LED/537 is wall rotary RF dimmer with 256 levels logarithmic dimming from 0.1-100%.
Simple and friendly use for dimming and switching ON/OFF for 1zone controlled.
Long time span battery for 2 years
1 Kanal Wandeinbaudimmer in
Wireless, easy to change battary
Parameter
zwei Farben
Remote
Operation
Part No.
Operation Voltage
Remarks
Frequency
Batteriebetrieb
43LED/537-W
3VDC
434MHz/868MHz
RF Wireless
43LED/537-S
3VDC
434MHz/868MHz
RF Wireless
für Einbau in Schaltdosen 68mm
Receiver
Part No.
Iuput Voltage
Current
Output
Kunststoffgehäuse mit
4x700mA
4x(8.4-25.2)W
43LED/531
12-36VDC
1x8A
1x(96-288)W
43LED/530
12-36VDC
Glasabdeckung in 2 Farben
Installation
Drehknopf in Aluminium
verwendbar mit 43LED/530
86 x 86/AL 26/ET 20mm
Lieferung inklusive Batterie CR2032
BestellNr.
Farbauswahl angeben
43LED/537-
W
weiß
S
43LED/537-
schwarz
0/1-10V dimmer
Model: 43LED/580
Installation
+
Wiring diagram
Power Supply
110V-230VAC
12-36VDC
43LED/530
Single color LED Strip
43LED/531
Single color LED Strip
Learning Key
RF Easy Dimmer
Single color LED Strip
GND
Feature
4x5A
Dimmmodul - 1 Kanal
With 1 Channel 0/1-10V signal Input, 1 Channel PWM Output
PUSH
Analog dim driver, receive standard 1-10V dim signal input
0-100% dimming range via logarithmic characteristic , perfect for human's vision
dimmbar mit Taster oder
256 levels of Grey scales, smoothly without any flash
To work with power repeater to expand output unlimitedly.
Can coordinate with 1-10 regulator or 1-10V dimmer to do analog dimming ,smooth dimming curve,
Single color LED Strip
GND
43LED/530
PUSH
RF Easy Dimmer
be in direct proportion to voltage curve of regular.
Funkfernbedienung
Parameter
Learning Key
Power Supply
110V-230VAC
Iuput Voltage
12-36VDC
Part No.
Current
Output
Eingangsspannung 12-24VDC, 1x 8A
43LED/580
12-36VDC
1x8A
1x(96-288)W
Mounting
The key part of this controller is a universal, extremely rotary standard switch element that can be integrated in
Brief introduction of buttons
numerous frames by different manufactures as below list:
L 95/B 37/H 20mm
BEKER
S1, B1, B3, B7 glass
GIRA
Standard55, E2, Event, Esprit
JUNG
A500, Aplus
1 channel 0/1-10V
43LED/580
MERTEN
M-smart, M-Arc, M-Plan
signal input
BestellNr.
43LED/530
0/1-10V dimmer
Model: 43LED/580
Installation
+
Wiring diagram
Power Supply
110V-230VAC
12-36VDC
43LED/530
Single color LED Strip
43LED/531
Single color LED Strip
RF Easy Dimmer
Learning Key
Single color LED Strip
Feature
GND
Dimmmodul - 1 Kanal
4x5A
With 1 Channel 0/1-10V signal Input, 1 Channel PWM Output
Analog dim driver, receive standard 1-10V dim signal input
PUSH
0-100% dimming range via logarithmic characteristic , perfect for human's vision
dimmbar mit Taster oder
256 levels of Grey scales, smoothly without any flash
To work with power repeater to expand output unlimitedly.
Can coordinate with 1-10 regulator or 1-10V dimmer to do analog dimming ,smooth dimming curve,
Single color LED Strip
be in direct proportion to voltage curve of regular.
Funkfernbedienung
43LED/530
PUSH
GND
RF Easy Dimmer
Parameter
Learning Key
Iuput Voltage
Part No.
Current
Output
Eingangsspannung 12-24VDC, 1x 8A
Power Supply
110V-230VAC
12-36VDC
43LED/580
12-36VDC
1x8A
1x(96-288)W
Mounting
Brief introduction of buttons
L 95/B 37/H 20mm
The key part of this controller is a universal, extremely rotary standard switch element that can be integrated in
numerous frames by different manufactures as below list:
BEKER
S1, B1, B3, B7 glass
GIRA
1 channel 0/1-10V
Standard55, E2, Event, Esprit
43LED/580
signal input
JUNG
A500, Aplus
BestellNr.
MERTEN
M-smart, M-Arc, M-Plan
43LED/530
Wiring diagram
0/1-10V dimmer
Model: 43LED/580
Power Supply
110V-230VAC
12-36VDC
43LED/531
Learning Key
RF Easy Dimmer
+
GND
4x5A
PUSH
GND
43LED/530
PUSH
RF Easy Dimmer
Learning Key
Power Supply
110V-230VAC
12-36VDC
43LED/530
Operation
Feature
Please pair remote and receiver, after finishing connecting receivers with LED lights correctly, base on
Dimmmodul - 1 Kanal
With 1 Channel 0/1-10V signal Input, 1 Channel PWM Output
diagram above.
Analog dim driver, receive standard 1-10V dim signal input
0-100% dimming range via logarithmic characteristic , perfect for human's vision
1. Press shortly the learning Key
on the receiver,then push the rotary button
dimmbar mit Taster oder
256 levels of Grey scales, smoothly without any flash
the LED lights will blink on the receiver. Do the same for the other receivers if you use them, you can add as
To work with power repeater to expand output unlimitedly.
many optional receivers as you want.
Can coordinate with 1-10 regulator or 1-10V dimmer to do analog dimming ,smooth dimming curve,
be in direct proportion to voltage curve of regular.
Funkfernbedienung
2. Short push rotary button
to switch ON/OFF
Parameter
Adjust dim brightness by the rotary button from left to right 0.1-100%
Adjust dim brightness by the rotary button from right to left 100-0.1%
Iuput Voltage
Part No.
Current
Output
Eingangsspannung 12-24VDC, 1x 8A
43LED/580
12-36VDC
1x8A
1x(96-288)W
Safety & Warnings
Remarks
Brief introduction of buttons
1) The product shall be installed and serviced by a qualified person.
L 95/B 37/H 20mm
Constant current
2) IP20.Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof
Constant voltage
enclosure.
1 channel 0/1-10V
43LED/580
3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.
signal input
BestellNr.
4) Please check if the output voltage of any LED power supplies used comply with the working voltage of the
product.
43LED/530
5) Never connect any cables while power is on and always assure correct connections to avoid short circuits
before switching on.
6)
Please ensure that the cable is secured tightly in the connector
7) For update information please consult your supplier.
Product Size
95.0
85.0
Wiring diagram
43LED/580
0/1-10V
Control Unit
Power Supply
AC110-230V
Input 12-36VDC
Safety & Warnings
1) The product shall be installed and serviced by a qualified person.
2) IP20.Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof
enclosure.
3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.
4) Please check if the output voltage of any LED power supplies used comply with the working voltage of the
product.
5) Never connect any cables while power is on and always assure correct connections to avoid short circuits
before switching on.
6)
Please ensure that the cable is secured tightly in the connector
7) For update information please consult your supplier.
Warranty Agreement
1) We provide lifelong technical assistance with this product:
3-year warranty. We print date on every products, for example :1125 means year 2011,week 25.The
warranty is for free repair or replacement and covers manufacturing faults only.
Remarks
For faults beyond the 3-year warranty we reserve the right to charge for time and parts.
Constant voltage
2) Limited Warrenty
Any defects caused by wrong operation.
Any damages caused by unauthorized removal, maintenance, modifying, incorrect connection and
replacement of chips.
Any damages due to transportation, vibration etc. after purchase.
Any damages caused by earthquake, fire, lightning, pollution and abnormal voltage.
Output
Any damages caused by negligence, inappropriate storing at high temperatures and humidity or near
harmful chemicals.
Power input 12-36VDC
Product has been updated
3) Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
Product Size
95.0
85.0
Wiring diagram
43LED/580
0/1-10V
Control Unit
Power Supply
AC110-230V
Input 12-36VDC
Safety & Warnings
1) The product shall be installed and serviced by a qualified person.
2) IP20.Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof
enclosure.
3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.
4) Please check if the output voltage of any LED power supplies used comply with the working voltage of the
product.
5) Never connect any cables while power is on and always assure correct connections to avoid short circuits
before switching on.
6)
Please ensure that the cable is secured tightly in the connector
7) For update information please consult your supplier.
Warranty Agreement
1) We provide lifelong technical assistance with this product:
3-year warranty. We print date on every products, for example :1125 means year 2011,week 25.The
warranty is for free repair or replacement and covers manufacturing faults only.
Remarks
For faults beyond the 3-year warranty we reserve the right to charge for time and parts.
Constant voltage
2) Limited Warrenty
Any defects caused by wrong operation.
Any damages caused by unauthorized removal, maintenance, modifying, incorrect connection and
replacement of chips.
Any damages due to transportation, vibration etc. after purchase.
Any damages caused by earthquake, fire, lightning, pollution and abnormal voltage.
Output
Any damages caused by negligence, inappropriate storing at high temperatures and humidity or near
harmful chemicals.
Power input 12-36VDC
Product has been updated
3) Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
Product Size
95.0
Single color LED Strip
Single color LED Strip
Single color LED Strip
85.0
Wiring diagram
43LED/580
0/1-10V
Control Unit
Single color LED Strip
Power Supply
AC110-230V
Input 12-36VDC
Safety & Warnings
1) The product shall be installed and serviced by a qualified person.
2) IP20.Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof
enclosure.
3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.
4) Please check if the output voltage of any LED power supplies used comply with the working voltage of the
product.
5) Never connect any cables while power is on and always assure correct connections to avoid short circuits
before switching on.
6)
Please ensure that the cable is secured tightly in the connector
.Once successfully learn,
7) For update information please consult your supplier.
Warranty Agreement
1) We provide lifelong technical assistance with this product:
3-year warranty. We print date on every products, for example :1125 means year 2011,week 25.The
warranty is for free repair or replacement and covers manufacturing faults only.
Remarks
For faults beyond the 3-year warranty we reserve the right to charge for time and parts.
Constant voltage
2) Limited Warrenty
Any defects caused by wrong operation.
Any damages caused by unauthorized removal, maintenance, modifying, incorrect connection and
replacement of chips.
Any damages due to transportation, vibration etc. after purchase.
Any damages caused by earthquake, fire, lightning, pollution and abnormal voltage.
Output
Any damages caused by negligence, inappropriate storing at high temperatures and humidity or near
harmful chemicals.
Power input 12-36VDC
Product has been updated
3) Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
Technische Datenbläter und Detailinfos - www.leuchtwurm.at/downloads
Single Color LED Strip
Single Color LED Strip
Single Color LED Strip
43LED/84
Dimmmodul - 1 Kanal
inklusive Funkfernbedienung
Eingangsspannung 12VDC oder
24VDC, 1x 18A
L 107/B 96/H 35
BestellNr.
43LED/84-12
43LED/84-24
Werbung
