NOTE: place the device front side (GPS antenna) upwards for optimum GPS/
GPRS range.
When the device is installed in a car, make sure the windscreen does not
consist of an insulation cover which may reduce the GPS signal and lead to
malfunction of the device.
Attention: device should be installed by a qualified person. Device should be
placed in a location where it will be protected from water, humidity and dust.
Connect wires as indicated on the illustration:
• Red wire connects to vehicle power positive +
• Black wire connects to vehicle power negative -
• Green wire connects to ACC wire
• Remaining wires connect to respective accessories
Owner's manual
TRACkER INSTALLATION
WIRES CONNECTION
