Allgemeiner Teil / General Section
Es gelten die Vorschriften und Sicherheitshin-
weise gemäß dem Service Manual "Sicherheit",
Materialnummer 72010 800 0000, sowie zusätz-
lich die eventuell abweichenden, landes-
spezifischen Vorschriften!
Inhaltsverzeichnis
D

Allgemeiner Teil ............................ 1 - 2 ... 1 - 7

Meßgeräte / Hilfsmittel .............................................................. 1 - 2
Technische Daten ..................................................................... 1 - 2
Bedienhinweise ......................................................................... 1 - 3
Schaltpläne und
Druckplattenabbildungen ........... 2 - 1 ... 2 - 12
Schaltplan Netzteil .................................................................... 2 - 1
Gesamtschaltplan ..................................................................... 2 - 3
Druckplattenabbildungen ........................................................ 2 - 11
Ersatzteilliste ................................. 3 - 1 ... 3 - 2
Allgemeiner Teil
Messgeräte / Messmittel
Beachten Sie bitte das GRUNDIG Messtechnik-Programm, das Sie
unter folgender Adresse erhalten:
Technische Daten
Programmplätze: ................................................................................ 299
Audioteil
Frequenzgang (DIN 45500): ............................................... 20Hz - 15kHz
Tonunterträgerfrequenz ........................... Einstellbar von 5,0 bis 9,0MHz
Deemphasis: ................................................................... 50µs, J17, 75µs
Bandbreite: ............................................................................ 130/280kHz
Empfang
Frequenzband: ................................................................... 920-2050MHz
Eingangsniveau: .......................................................... 47-77dBµV (75Ω)
Eingangsbandbreite: ..................................................................... 27MHz
Demodulator: ...................................................................................... FM
Schnittstelle zur Satellitenantenne
Eingang: ............................................................... Anschluß vom Typ »F«
LNB-Spannung: .................................................. 0V / 14V / 18V (300mA)
Polarisatorsteuerung: ....................................... Typ »MARCONI« (14/18)
Schaltsignal: .................................................................. 22kHz (EIN/AUS)
Verschiedenes
Stromversorgung: ............................................................... 230V~ / 50Hz
Energieverbrauch: .......................................................................... ≤ 40W
Bruttogewicht: ..................................................................................... 3kg
Abmessungen (H x B x T): .......................................... 72 x 365 x 230mm
Anschlüsse
TV-Gerät: .................................................................... Euro-AV-Anschluß
Videorecorder: ............................................................ Euro-AV-Anschluß
Decoder: ..................................................................... Euro-AV-Anschluß
Audio: ................... Cinchstecker (RCA)/linker und rechter Kanal/500 mV
UHF-Modulator: ..... Kanäle 30 bis 45 einstellbar/eingestellt auf Kanal 43
Eingang terrestrische Antenne .............................................. IEC-Buchse
Ausgang terrestrische Antenne ............................................. IEC-Stecker
1 - 2
Seite
GRUNDIG Instruments Test- und Messsysteme GmbH
Würzburger Str. 150, D 90766 Fürth/Bay
Tel. 0911/703-4118, Fax 0911/703-4130
eMail: instruments@grundig.de
Internet: http://www.grundig-instruments.de
< 15W Standby
The regulations and safety instructions shall be
valid as provided by the "Safety" Service Manual,
part number 72010 800 0000, as well as the
respective national deviations.
Table of Contents
GB

General Section ........................... 1 - 2 ... 1 - 12

Test Equipment / Aids ............................................................... 1 - 2
Technical Data .......................................................................... 1 - 2
Operating Hints ......................................................................... 1 - 8
Circuit Diagrams
and Layout of PCBs .................... 2 - 1 ... 2 - 12
Circuit Diagram Power Supply .................................................. 2 - 1
General Circuit Diagram ........................................................... 2 - 3
Layout of PCBs ....................................................................... 2 - 11
Spare Parts List ............................. 3 - 1 ... 3 - 2
General Section
Test Equipment / Aids
Please note the Grundig Catalog "Test and Measuring Equipment"
obtainable from:
Technical Data
Programme positions: ........................................................................ 299
Audio Unit
Frequency response (DIN 45500): ...................................... 20Hz - 15kHz
Subcarrier frequencies: ................................ Tunable from 5.0 to 9.0MHz
De-emphasis: .................................................................. 50µs, J17, 75µs
Bandwidth: ............................................................................ 130/280kHz
Reception Unit
Frequency band: ................................................................ 920-2050MHz
Input level: .................................................................... 47-77dBµV (75Ω)
Input bandwidth: ............................................................................ 27MHz
Demodulator: ...................................................................................... FM
Satellite aerial interface
Input: ......................................................................... Type »F« connector
LNB voltage: ....................................................... 0V / 14V / 18V (300mA)
Polarisation command: ................................... »MARCONI type« (14/18)
Switching tone: .............................................................. 22kHz (ON/OFF)
Miscellaneous
Power supply ...................................................................... 230V~ / 50Hz
Consumption: ................................................................................. ≤ 40W
Gross weight: ...................................................................................... 3kg
Dimensions (H x W x D): ............................................. 72 x 365 x 230mm
Connections
TV: ................................................................................... Euroconnector
VCR: ................................................................................. Euroconnector
Decoder: ........................................................................... Euroconnector
Audio: ....................... Cinch (RCA) plug / left and right channels/ 500 mV
UHF modulator: ...................... Tunable from 30 to 45 / set on channel 43
terrestrial aerial input .............................................................. IEC socket
terrestrial aerial output ................................................................. IECplug
STR 6000
Page
< 15W stand-by
