1. Features & Applications
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm
the environment. Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to
a specialized company for recycling. This device should be returned to your distributor or to a local recycling
service. Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for buying the CS200 metal detector. Read this manual carefully before bringing the device into service.
With your CS200 metal detector, you can search for coins, relics, jewellery, gold, and silver just about everywhere.
The detector is easy to use. Its features include:
LCD Display
Three Tone Audio Discrimination : sounds distinctive tones for different types of metals.
Notch
Headphone Jack
Waterproof Search Coil
Note: Your metal detector requires two 9-volt alkaline batteries (not supplied)
2. Preparation
a) Assembling the detector
1- search coil
2- search coil fixation system
3- stem
4- lock nut
5- cable
6- control housing
7- arm support
Assembling your detector is easy and requires no special tools. Just follow these steps:
1. Remove the fixation system of the search coil (nut and bolt system). Insert the stem and align the holes on the
search coil bracket and the stem. Push the bolt through the holes and tighten with the nut knob.
CAUTION: Do not tighten the search coil fixation too hard. Don't use tools such as pliers to tighten it.
2. Insert the arm support into the end of the stem and tighten the lock screw at the back of the control housing.
3. Turn the stem's lock nut clockwise until it loosens.
4. Adjust the stem length to have the search coil level with and about ½ to 2 inches above the ground when you
stand upright with the detector in your hand, your arm relaxed at your side.
5. Turn the stem's lock nut counter-clockwise to lock it in place.
CS200_v2
CS200 – METAL DETECTOR
: indicates the probable type of metal with an arrow, the depth of the target,
DISC/NOTCH range, the level of sensitivity, the operating mode, and low
battery indication.
: ignores junk metal and finds valuable items by setting the disc and notch
range.
: lets you connect headphones (not supplied) and operate without trouble
: use the detector even if you must put it under water.
