Always turn OFF the input power supply and wait until the CHARGE indicator
light goes out before wiring terminal. Otherwise, an electric shocks or fire can occur.
Do not touch the Braking unit and Braking resistor while power is applied to the
circuit. Failure to observe this warning can result in personal injury.
Wiring should be performed only by qualified personnel. Failure to observe this
warning can result in an electrical shock or a fire.
Make sure to earth the ground terminal
class 100Ω or less, 400V class 10Ω or less.
When wiring the emergency stop circuit, check the wiring thoroughly before
operation.Failure to observe this warning can result in personal injury.
Never touch the fins (heat-sink) of the Braking unit or discharge resistor. These
can become very hot. Failure to observe this warning can result in personal injury.
Install the discharge resistor on nonflammable material, provide sufficient
spaces from other devices, the 1 meter distance are recommend, Failure to observe this
caution can result in a fire.
Verify that the rated voltage setting jumper of the braking unit coincides with the
Inverter input supply voltage. Failure to observe this caution can result in personal injury
or a fire.
Tighten terminal screws to the specified tightening torque. Failure to observe
this caution can result in a fire.
Do not perform a withstand voltage test of the braking unit and braking resistor
unit. It may cause braking unit inside element to be damaged.
─────────────OPERATION────────────
Do not remove the cover while the power is ON, current is flowing. Failure to
observe this warning can result in an electrical shock.
Do not check signals during operation. The Braking unit or the Inverter may be
damaged.
, Grounding resistance 200V
4 4
