6. TYPICAL SYSTEM SET UP
PLANT AIR MUST BE PROPERLY
FILTERED AND DRY. IF NOT, SPECIFY
A 5-MICRON FILTER REGULATOR.
TS5622VU-DVD
DIAPHRAGM VALVE
TECHCON SYSTEMS TS5130 FLUID FEED SYSTEM
CONTROLLER OR EQUIVALENT TS1258 OR EQUIVALENT
MATERIAL
CONSTANT AIR
PULSED AIR
Figure 5.0
