SITOP power 5 6EP1333-1AL12 SITOP power 10 6EP1334-1AL12 Betriebsanleitung Best. Nr.: C98130-A1236-A2-1-6419 Operating instructions Instructions Istruzioni di servizio Instrucciones SITOP power 5 120/230V AC Adjust 24V DC + + + - - - 24-28,8V SIEMENS AG ÖSTERREICH, 03.2002 SITOP Power 5/10...
Seite 2
Ai fini della chiarezza le presenti istruzioni di servizio non contengono tutte le informazioni dettagliate su tutti i tipi del prodotto e non possono nemmeno trattare tutti i casi di installazione, di esercizio o di manutenzione. Per ulteriori informazioni rivolgersi alla filiale Siemens di zona o consultare la homepage http://www.siemens.de/sitop.
L1, N (L2) Eingangsspannung 0,14...2,5mm Schraubklemmen; Verwenden Sie einen Schraubendreher mit 3,5mm Klingenbreite. Empfohlenes Anzugsmoment 0,5...0,7Nm Schutzleiter 1, 2 Ausgangsspannung DC 24 V 0,14...2,5mm Schraubklemmen; Verwenden Sie einen Schraubendreher mit 3,5mm Klingenbreite. Empfohlenes Anzugsmoment 0,5...0,7Nm SIEMENS AG ÖSTERREICH, 03.2002 SITOP Power 5/10...
3.5 mm. Recommended tightening torque 0.5-0.7 Nm 1, 2 Output voltage DC 24 V 0.14 to 2.5mm Screw-type terminals. Use a screwdriver with a blade width of 3.5mm. AWG 22 to 12 Recommended tightening torque 0.5-0.7 Nm SIEMENS AG ÖSTERREICH, 03.2002 SITOP Power 5/10...
Conducteur de protection Couple de serrage recommandé 0,5-0,7Nm 1, 2 Tension de sortie 24 V cc 0,14...2,5mm Bornes à vis. Utiliser un tournevis à lame de 3,5mm de large.serrage Couple de serrage recommandé 0,5-0,7Nm SIEMENS AG ÖSTERREICH, 03.2002 SITOP Power 5/10...
Conduttore di protezione Coppia di serraggio consigliata 0,5-0,7 Nm 1, 2 Tensione di uscita DC 24 V 0,14...2,5mm Morsetti a vite. Impiegare un cacciavite con tagliente di 3,5mm. Coppia di serraggio consigliata 0,5-0,7 Nm SIEMENS AG ÖSTERREICH, 03.2002 SITOP Power 5/10...
Par de apriete recomendado 0,5-0,7Nm Conductor de protección 0,14...2,5mm 1, 2 Tensión de salida DC 24 V 0,14...2,5mm Bornes de tornillo. Usar un destornillador con hoja de 3,5mm de ancho. Par de apriete recomendado 0,5-0,7Nm SIEMENS AG ÖSTERREICH, 03.2002 SITOP Power 5/10...
