Before commissioning

Before you can use your internet radio, streaming functionality or using a smartphone app, you will need:
•
A quick Internet access.
•
A router, preferably with WL AN (wireless access point).
•
If your router does not provide WL AN, you can also connect your device via an Ethernet cable
•
Later on, when setting up the device, choose between wireless (WL AN) and cable connection.
•
If your wireless network is set to Wired Equivalent Privacy (WEP) or Wi-Fi Protected Access
(WPA), you will need the WEP or WPA code, so that your Internet radio can exchange data with
the router.
•
Before you continue, make sure that your wireless network is switched on and has broadband
internet access.
•
If you have any problem connecting your device to your router, please, tr y to solve them by
consulting the router's operating manual.
38
1
16 3 2 4

Operating elements on the device

1.
Colour display.
2.
3,5mm line-in input jack for media players.
3.
6,3mm Headset Jack.
4.
USB input jack.
5.
„Back" button: press this button to return to the
previous menu item.
6.
„CD" button: opens or closes the CD case.
With the first pressure of this key, the device
changes to "CD" operation mode.
7.
Multifunction knob: with left / right rotation,
the volume can be raised or lowered. Press the
menu key, on the menu mode, the single points
are selected by turning and activated by pres-
sing the multifunction rotary knob.
8.
Cd compartment
9.
"Menu" button: by pressure of this key, you
reach in the system menu.
10.
„Source" button: by pressing this button re-
peatedly the devices will be connected in a se-
quence to its sources.
11.
Button to switch between loudspeaker pair A, B
5 7 8
6 9 10 11 12 13 14 15 17
and A + B.
12.
„Replay / pause" button: after a simple pressure,
the device stops on pause, after a repeated one,
it continues on replay mode. If you press it for 5
seconds, the device will be on stop mode. This
key function is valid for CD and media players.
13.
Back" button: press this button to return to the
previous menu item.
14.
„Forward" button: press this button on radio
mode and the device searches automatically
the next transmitter. On CD and media player
mode, the device changes to the next track.
15.
"Clock" button: it changes the display to show
to time and the date. You press it again to return
to the last function.
16.
Display of the activated loudspeaker pair.
17.
"Power" button: press this button to turn the
unit on and off (Real power disconnector).
