LCA/CVBS
switch
With the
LCA/CVBS
switch
Jl
m
you can
either
choose
the
LCA
signal or
the
CVBS
signal.
oo
TTLRGB
Un.
RGB
Connection
(left
panel)
Headphones
On
the
left
side of
the monitor
you
will
find
a
3,5
mm
jack-type
socket
for
connecting
the
headphones.
D
TTL
RGB
input
(8
pin
DIN
type 270°)
For connection
of
a computer
with
a
TTL
RGB
output with
separated
synchronisation
(TTL
level).
RGB
linear
input
(6
pin
DIN type
270°)
For connection of a
Video Recorder,
Computer, LaserVision Player,
TV
Tuner,
etc.
Remark:
If
you connect both
RGB
inputs
simultaneously the
TTL
RGB
input
automatically
has
priority
over the
linear
RGB
input.
After switching
off
or
removing
the
connection cable
from
the
TTL
source,
RGB
linear will
be looped
in.
Operation
Switching
on
©
•
Press button
©
(LED
lights
up).
Switching
off
©
•
Press
button
©
again.
and sound
controls
For an
optimum
adjustment
of
the video
and audio input signals
various controls are
available.
Open
flap
0.
