2.2. SETTING UP RTGTC RACK

Dimensions : L 482 x H 44 x P266 mm.
Face avant fixation
Mounting of front panel

2.3. CONNECTION

Face avant
► Wall mount case
Face arrière
8,7
Profil
► Programming buttons + LCD screen
42
464.5
482
464,6
Force
266
AUT OFF ON
C4
N°4
Force
AUT OFF ON
C3
N°3
Force
AUT OFF ON
N°2
Force
AUT OFF ON
C1
N°1
Pulse
Output
IRIG B / AFNOR
Output
Sources of synchronisation
Input signal (antenna)
RS485 RS232
R- NC
T- TXD2
R+ RXD1
T+ TXD1
GND GND
C4
C3
MANUAL
C2
CONTROL
C1
COM
C4
C3
C2
L
C1
N
230 VAC
L
GROUND ( )
required
230 VAC
N
MDE-Radio-Timing-GTC-3080V2.3
